Vacuum Hopper Hopper Automatic Extrusion Blowing Blow Molding Moulding Machine

Product Description

Scope of application: "One-to-More" Separate hopper loaders are designed and developed on the basis of original separate-vacuum Hopper Loaders. They feature more functions, easy to operate, and convenient to install. This model, equipped with a high pressure blower and more hoppers, is applicable to more dehumidifying and drying machines (dehumidifying dryer "CDD" or one gravimetric blenders "CGB" to process plastic materials. Besides that , it can also realize the one-to-more way of conveying materials to different moulding machines or hoppers to greatly lower the cost.
Feature:

1.One-to-More" hopper loader can greatly lower the cost.

2.The dust collection chamber features a cyclone separator and a dust collective bin to effectively reduce the load of the filter.

3.Separate hopper receivers are designed in classy standard style, made by stainless steel, and bringing no contamination to materials.

4.One-piece PLC controller, the operation is simple, reliable performance

5.Motor protection device.

6.Standard audible and visual alarm device configuration.

7.When conveying materials of tiny impurity is more, or contain recycling materials, host optional store pressure tank automatic cleaning device.

Note: 1) Power supply:30PH400V50Hz 2) Test condition of conveying capacity: Plastic material of bulk density 0.65, dia.3 ~ 5 mm, vertical conveying height: 4m, horizontal conveying distance: 5m. 3) CHR stands for vacuum hopper, CHR-E stands for photo-sensor hopper. 4) Optional filter cleaning device (model denotes "C") and air accumulator (model denotes "A") available for automatic filter cleaning, (for 3.5HP-G up) 5. We reserve the right to change specifications without prior notice.

Specifications:

Main unit				Hopper Receivers				Conveying Pipe Dia. (inch)	Conveying Capacity (kg/hr)
Model	Motor Power (kW)	Size (mm)	Weight (kg)	Model	Volume (L)	Size (mm)	Weight (kg)
CUL-1HP-G	1.1	860 x 360 x 420	50	CHR-6	6	420x285x360	6	1.5"	300
				CHR-6-E		600x275x360	8
CUL-2HP-G	1.6	860x360x420	54	CHR-12	12	470 x 315 x 400	7	1.5"	500
				CHR-12-E		700 x 315 x 400	12
CUL-3.5HP-G	2.2	1340x515x500	73	CHR-24	24	690 x 315 x 400	9	2"	750
				CHR-24-E		1120 x 360 x 400	13
CUL-5HP-G	4	1340x515x500	74	CHR-24	24	690 x 315 x 400	9	2"	1000
				CHR-24-E		1120x360x400	13
CUL-7.5HP-G	5.5	1780 x 660 x 600	156	CHR-36	36	930 x 315 x 400	11	2"	1200
CUL-10HP-G	7.5	1780 x 660 x 600	160	CHR-36	36	930x315x400	11	2"	1600
CUL-15HP-G	12.5	1940x700x800	226	CHR-48	48	975x350x475	15	2.5"	2000

---
