High Accuracy GPRS GPS tracking counting system Camera bus passenger counter with RS232 / RS485 port

Product Details

Product Description

Product Description
High Accuracy GPRS GPS tracking counting system Camera bus passenger counter with RS232 / RS485 port
We have two models of people counter ,one is with the function of recording i.e DVR function ,specifically 4ch HDD GPS 3G mobile dvr with people counting; the other model is the new one GPRS people counter not have the function of recording, but simple and can integrate into your platform. We can customize more projects. Welcome to browse our offical website for more examples.
FEATURE
* RS232/485
* GPS location and tracking
* Bus people on/off counting.
* Ability to determine passenger movement direction.
* The possibility of simultaneous detection of two people passing in
* Possible integration with MDVR or ticketing system
* The People counter case is made in accordance with IP54 standard, which enables the device resistance to moisture and dust.
* Customer can customize their applications flexibly.
Obtaining passenger data(Latitude and longitude of station, date and time, counter) from RS232/485 port
Option
*Support 2G(GPRS) transmission(TCP IP Transfer Mode)
*Report of the counting stored in SD storage and server.

System	OS	Linux3.0
	CPU	TMS320DM6446
	Operating Interface	OSD with mouse and remote control
Alarm	Shelter Alarm	Alarm alert stored in SD card and saved in server when camera is sheltered
Network	Wireless Transmission	Supporting GPRS
Locating	GPS (Optional)	Supporting external GPS
Interface	Standard Interface	Supporting 1 RS232 ports ,1 RS485 port
	External Antenna	Antenna interface with embedded GPS
	Standard Interface	Standard RJ45 interface, with indicator.
	Standard Interface	Compatible with commerciall avaiblable brands.
	System Upgrading	Supporting SD card upgrading and remote upgrading
Gate Control	Door Sensor	High/low electric level trigger
	GPS speed	Threshhold 8KM/H
Power Supply and Power Consumption	Power Supply	1. ACC on/off 2. SD card lock on/off 3. Delayed shutdown 4. Timed on/off
	Input Voltage	DC:+8V ~ +36V
	Power Consumption	<4W in normal operation
Operating Environment	Temperature	Normal: -20℃ ~ +80℃
	Humidity	10% to 95%
Package	Dimension	160(W) x62(H) x200(D) mm.
	Weight	Net: 2200g, Gross: 3500g

---
