New Design Small Mixed Dumper (HY40) for Sale

Product Description

HY series mixing dump truck is a new practical products that is my company independent research and development, engineering machinery suitable for multi-purpose high efficient transport of bulk materials. Applicable to small and medium-sized civil engineering, city construction, road construction, bridge construction and environmental health site operation, used for short distance transport scarification, sand, coal, furnace concrete loose material.

The machine features

1, Great practicability, wide range of uses . With compact structure, beautiful appearance, reasonable arrangement.

2, using hydraulic transmission, make full use of the power of the engine, machine is simple, comfortable, with high economic and production efficiency.

3, the use of four wheel drive, special tire engineering machine, swing bridge, has good road performance, the performance and more traction.

4, the braking system adopts pneumatic clamp type brake, the braking force, safe and reliable.

5, using the open field of vision, the elastic support cab, comfort operation safety.

6, the cab tilting system, convenient maintenance repair parts under the cab.

specification		note
engine	China huafeng 4102	4 ylinder
	power	47Kw
	speedr/min)	2400
gearbox	hydraulic gearbox	torque converter
axle	reduction axle
brake system	hydraulic brake
steering system	whole hydraulic steering frame
drive model	4 wheel drive
	Electrical start	with Bucket mixing function
A L	4700mm
B H	2750mm
C W	2400mm
D wheel base	2090mm
E max ground clearance	240mm
F bucket to the ground	1620mm
G wheel distance	1560mm
J Max turn radius	35°
width of the bucket	2400mm
capacity of the bucket	2m³
rated load	4000kg
drive speed
forward	0-28Km/h
backward	0-28Km/h

---
