Model
| BME-500D
| BME-500E
| BME-500SM
| BME-500V
|
Viewing head
| Monocular Head Inclined at 45°,360° rotatable
| Compensation Free Binocular Head Inclined at 30°,360° rotatable
| Compensation Free Trinocular Head,360° rotatable
| Dual viewing head, one tube 30°,inclined and another tube vertical, 360° rotatable
|
Achromatic Objectives
| 4X,10X,40X(S),100X(S,Oil)
|
Eyepiece
| Wide Field Eyepiece :WF10X,(WF16X optional)
|
Stage
| Double Layer Mechanical Stage Size 120*125mm
|
Focusing
| Coaxial Coarse and Fine Adjustment, Focusing Range 30mm, Focusing Interval 0.002mm
|
Condenser
| Abbe NA=1.25 with lris Diaphragm&Filter
|
IIIumination
| LED(1W) Lamp 220V or 110V ( LED 3W lamp optional, Halogen bulb 6V/20W optional)
|
Package Size
| 370*230*470mm
|
Gross Weight
| 5kg
|
