Horizontal Turning Center CNC Lathe Machine with 650mm Swing Diameter

Product Description

Product Description
Introducing the Automatic Metal TCK50 Horizontal Metal Slant Bed CNC Lathe - a marvel of modern engineering, designed for precision and efficiency in metalworking.
1. TCK-50 features an innovative design that incorporates a 45° inclined layout and a robust integrated bed base structure. This design significantly enhances the machine's bending and torsional rigidity, ensuring high stability and unmatched performance-a testament to its robust engineering.2. TCK-50's Spindle Unit showcases exceptional craftsmanship. It utilizes high-precision NSK spindle bearings for unparalleled unit precision and rigidity. Undergoing strict dynamic balance testing, the spindle system boasts outstanding accuracy, excellent accuracy retention, minimal thermal deformation, and superior thermal stability, operating at speeds up to 2600rpm.3. The TCK-50 is equipped with a hydraulic knife tower, offering users convenience, practicality, and dependable performance in processing tasks.4. TCK-50 is equipped with an impeccable hydraulic and lubrication system, featuring a high-quality hydraulic pump and components, which significantly reduce failure rates. Its design is simple yet reliable, with centralized and automatically adjusted lubrication.5. The driving motor and ball screw utilize an elastic coupling, ensuring precision transmission with no clearance. This design also provides superior protection for the machine tool.6. This machine tool is powered by a servo main motor, enabling stepless speed regulation for stable operation. It ensures constant linear speed cutting for parts, delivering high surface quality.
Detailed Photos
The TCK-50 CNC lathe incorporates a box structure bed crafted from high-strength Mihanna cast iron. Its compact structure offers impressive strength, suitable hardness, and low friction coefficient, along with self-lubrication. The integral box structure of the base bed significantly boosts the machine's rigidity and stability. This design includes vibration absorption to reduce tool wear and enhance workpiece quality. With its high performance-price ratio, strategic layout, speed, precision, and rigidity, it guarantees high efficiency and reliability for users.
Product Parameters

Specification	TCK50	TCK56	TCK600	TCK1000	FCK56
Max. swing diameter on the bed (MM)	500	560	600	560	650
Max. cutting diameter (MM)	360	330	550	350	530
Max. cutting length (MM)	500			1000	540
X-axis travel(MM)	200		280	200	280
Y-axis travel(MM)	±50
Z-axis travel	550	450	550	1050	750
X-axis moving speed (M/MIN)	30
Z-axis moving speed(M/MIN)	30
X-axis positioning accuracy	0.008mm
X-axis repeatability	0.005mm
Z-axis positioning accuracy	0.008mm
Z-axis repeatability	0.006MM
Spindle speed(RPM)	50-4500		50-3500	50-4500	50-4500
Main motor power	11kw
Main motor torque	72N.M
Weight (KG)	3600	4500	4300	4500	4200

Hot Sale Products
Packing and Delivery
Company Profile
Henan Rowdai Machinery Equipment Co., LTD Located in the bustling city of Zhengzhou, Henan Province, we specialize in the manufacture of CNC machine centers, Lathe machines, CNC Lathe Machines, Milling Machines, CNC Milling Machines, Grinding Machines, and Band Saws. Our products have found applications in the automotive, mold, construction machinery, aviation, high-speed railway, and energy industries. With a robust presence in multiple markets, our products are extensively exported across Europe, America, Australia, the Middle East, Southeast Asia, and Africa.
Our workforce boasts over a decade of experience with machine tools, supported by a team of professional inspectors dedicated to meeting customer needs. We prioritize quality machinery and impeccable after-sales service. Our offerings include:
1) Rigorous quality control
2) Highly competitive pricing
3) Cutting-edge technology products
4) The industry's best professional team in lifestyle consumer electronics
5) Seamless communication
6) Efficient OEM & ODM services
FAQ
1:How can I choose the most suitable machines ?
A: Please tell me your specifications ,we can choose the best model for you , or you can choose the exact model . You can also send us the products drawing ,we will choose the most suitable machines for you .
2: What's your main products of your company?
A: We specialized in all kinds of machines ,such as CNC Lathe Machine ,CNC Milling Machine ,Vertical Machining Center ,Lathe Machines ,Drilling Machine ,Radial Drilling Machine ,Sawing Machine ,Shaper machine and so on .
3: Where is our factory located? How can I visit there?
A : Our factory is located in Tengzhou City ,Shandong Province,277500 China. You are warmly welcomed to visit us.
4. What is your trade terms?
A : FOB, CFR and CIF all acceptable.
5: What's the Payment Terms ?
A : T/T ,30% initial payment when order ,70% balance payment before shipment ; Irrevocable LC at sight .
6: What's the MOQ?
A: 1 set .(Only some low cost machines will be more than 1 set )

---
