Product Details
Product Description
Product Description
Laser Particle Counter ND-6330S
Laser particle counter ND-6300(1CFM/ 28.3L/min or 50L/min) is a kind of instrument used to measure the size and quantity of dust particles in unit volume air of clean environment, which can directly detect A and D class clean environment. With features of using diode laser light source, large touch-screen display, small size, light weight, high precision, simple operation, microprocessor control, storing & printing the measurement results and so on, this product is widely used in electronics, optical, chemical, food, cosmetics, health,biological products,aerospace, etc.
User friendly interface-color touch screen operation, stainless steel shell, no buttons, easy to clean.
Small size,light weight-portable and easy to transport
Low noise fan, with a theoretical lifespan of 20000 hours
Automatic flow regulation function
6 channels display
95% UCL calculation, automatic determination of cleanliness level
Capable of printing, storing, and U disk output
Optional accessories ,such as compressed air (e.g. GC101, etc.)
Audit tracking function（optional）
Model
| ND-6330S
|
FLow Rate
| 28.3L/min
|
Channel
| 0.3,0.5,1.0,3.0,5.0,10.0μm
|
Overall dim.(cm)
| 23x 18x 18cm（WxDxH）
|
Display
| 7-inch ultra large LCD display screen
|
Weight(approx.）
| 4.5kg
|
Standard
| Automatic calculation, C-GMP ,EU-GMP,GMP（2010）、ISO-14644-1:2015,ISO14644-11999 total 7 types
|
Cycle
| 0-9999sec
|
Zero Count
| ≤10min
|
Printer
| Built-in Thermal Printer
|
Power Supply
| DC 12.6V built-in battery
|
Power
| 50W
|
Maximum sampling concentration
| 35000 P/L
|
Working Time
| 10 hours
|
Light source and lifetime
| Semiconductor laser (with a lifespan greater than 30000 hours)
|
Storage
| Sampling 8000
| Report 800
|
Environmental condition
| Temperature10℃-35℃,Humidity20%-75%,Pressure 86kPa-106kPa
|
>>
