Series Digital Charpy Impact Tester

Product Description

Product Description
Product DescriptionSeries Digital Charpy Impact TesterAT421D Series Digital Charpy Impact Tester (original HY4251D) is used to determine the impact toughness of non-metallic material such as rigid plastics, fibre reinforced composite material, nylon, glass, ceramics, cast stone, asbestos board, electrical insulating material, etc. It is suitable for notched and unnotched specimen. FeaturesModelAT421DAAT421DBImpact velocity2.9m/s3.8m/sImpact energy(0.5J), 1J, 2J, 4J, 5J7.5J, 15J, 25J, 50JImpact center distance230mm380mmPendulum angle150°150°Radius of striking edgeR=2±0.5mmR=2±0.5mmRadius of jawR=1±0.1mmR=1±0.1mmInclined angle of striking edge30±l°30±l°Energy display resolution0.01J0.01JJaw support spacing40, 60, 62, 70mm40, 60, 70, 95mmPower supplyAC220V 50HzAC220V 50HzDimensions420×260×630mm460×330×745mmWeight60kg70kgPaymentPayment Term T/TEXW30% T/T in advance, paid the balance before shipmentFOBCFR(C&F)30% T/T in advance, paid the balance against copy of B/LCIF L/CL/C amount above 50,000 usd, we can accept L/C at sightWest UnionAmount lower than 5000usdWest UnionDelivery Time7~10days after receiving payment for one containerPacking & DeliveryPackagingWeight60kgPackaging Details1. The equipment is covered with film is protect it from water vapour during the trip.2. The box is filled with foam to protect the equipment from impact. 3. Exported wooden box made from plywood, don't need fumigated.Contacting UsCompany Introduction

---
