Screw Type Air Compressor for Machinery

Product Description

Statement
A. Compressor lubricating oil is to ensure that an important factor in life, use the KR
air compressor oil, the oil if the user caused by use of poor quality air compressor
piston rings, connecting rod, cylinder and other parts of early wear and tear, are not covered under warranty inside.
B. In maintenance, you must use the products the company offers accessories, such
as the use of non-parts of the company's products, the company which products will not bear any responsibility.
C. Read the instruction manual, the correct use and maintenance, as a result of
improper installation, operation or repair, the user's negligence, natural disasters,
war or violence are not caused by failure in the warranty.
D. During the warranty period, the manufacturing numbers by the removal, those who
wear or forged change, the company no longer provides free repair services and
replacement parts.
E. the Company due to the machine for indirect damage caused, the Company shall
assume the responsibility for compensation.
F. Forbidden to increase safety valve opening pressure. Without our permission, any
increase in system pressure valve, the pressure generated by the pressure switch
and the Company shall not be responsible for the accident.
G. Compressor oil, air filter elements are consumed, he should be replaced based on
usage, its replacement is not the normal consumption of the warranty.
I.Safety Tips
A. The output of the compressor of the gas contains other impurities, may not be
directly used for artificial respiration.
B. Supporting the pressure vessel must be able to meet the rated working pressure of
the compressor; otherwise it will result in container explosion accidents. Pressure
vessel pressure test should be done regularly, press 5-year inspection cycle time,
other industrial machines for 10 years once.
C. Prohibits the safety valve opening pressure increased, the safety valve check at
least once a year, relevant departments under the deadline pressure gauge should
be calibrated, the system pressure valves, pressure switches, solenoid valves and
check valves should be regularly checked to ensure that they are in normal state.
D. Any repair, maintenance must be cut off the power and release the pressure under
the state and set warning signs. Crankcase should be parking at least 15 minutes
to open.
E. Compressor work, non-touch moving parts, high-speed moving parts will cause
serious damage to the human body. Do not remove the moving parts of the
protective device.
F. Compressor work, forbidden to touch the exhaust tubes, brass outer surface of the
exhaust temperature is high, it will burn the skin.
G. Prohibit the use of xylems, acetone or harmful volatile flammable cleaning agents to scrub parts, the parts should be rinsed clean dry.
II.Features and uses
A. The company's low-pressure air compressors are oil lubricated energy efficient, stable, secure, reliable, long service life.
B. A new design and production of dynamic balancing, vibration, smooth running machine.
C. Using high quality imported monomer cast piston rings, cylinder seals to ensure that the Upward and the prevention of oil, long life.
D. Air compressor, one-way valve has a national patent (Patent No.
ZL2007201424139), vertical lift valve is closed, no friction, greatly extend valve life.
E.Gas valve, Switzerland imported materials, long service life, and life without
fracture.
The company produces low-pressure reciprocating piston air compressors are widely used in water, PET bottle blowing, leak detection, textiles, painting, military and
other fields, in various fields to provide users with high quality and efficiency of the ideal gas source.
III.The main performance parameters

type		Displacement	Exhaust Pressure	Motor Power	Rpm	Weight	Shape Size	Unloading Way
		m³/min	MPa	KW	r/min	KG	L×W×H mm
Low-type	TA100	1.0	0.8	7.5	900	330	1520×615×1186	Electronic Control
	TA120	1.5	0.8	11	800	440	1680×685×1300	Electronic Control Or pores
	TA125	2.0	0.8	15	850	465	1680×715×1305	Electronic Control Or pores
Medium- pressure	KRW0.63/30	0.63	3.0	7.5	800	380	1490×610×1166	Electronic Control Or pores
	KRW1.0/30	1.0	3.0	11	660	580	1680×715×1330	Gas-electric double control
	KRW1.2/30	1.2	3.0	15	800	590	1680×745×1360	Gas-electric double control
	KRW1.2/30D	1.2	3.0	15	800	400	1420×710×885	Gas-electric double control
	KRW1.4/30	1.4	3.0	15	880	610	1680×745×1365	Gas-electric double control
	KRS1.6/30H	1.6	3.0	18.5	720	600	1070×820× 1490	Gas-electric double control

The company's products in continuous research and improvement, such as type, change without prior notice

---
