Product Description

Characters and graphics FSTN COG LCD display module Product Description
General Specification:
Detailed Photos
LCD Image:
The following are similar products:
Product Applications:
Delivery Details:
Ready-made Sample: within 1 week
Custom Sample: 1~2 weeks
Mass production: 3-4 weeks
Our Advantage:

Rich experience	Good knowledge of the displays market to put together solutions that add value and provide a unique proposition for the client
Advanced Equipment	Full automatic FPC&IC bonding machine, film attaching machine, CNC machine, polish machine advance production equipment ensure product quality
Quality Assurance	Advance inspection instrument and equipment to ensure 100% inspection for each and every piece before shipment
Fast response	Quickly realize your customized ideas, and have a sample ready in short time
Low MOQ	Depends on product
Stable supply	1~10 years supply period
Extensive range	Providing complete solution from Mono to Color LCD module, Optical bonding between display to cover glass as well as cover glass to touch screen
Large production capacity	Operation capacity 2KK monthly
Quality guarantee	RoHS compliant
Management	ISO 9001:2008, ISO 14001:2004

Company Profile
Product Line:
☆ Clean Room class 10k@0.8um, Pressurec 0.8kgf
☆ Antistatic floor, resistance : 1x10 ohm to 1x10 ohm
☆ COG production lines: 4 .
☆ Backlight production lines: 2 .
☆ Existing machine capacity will be 1KK per month.
***In compliance with ISO9001: 2008 Quality Management
***One year's guarantee for unartificial damage
1: Small lcd display screen
2: Reasonable price
3: Large capacity
4: Certificate ISO; Rohs, REACH
5: Dimension as customer request
6: STN blue small lcd display screen
------------------------------------------------------------------------------------------------------------------------------------
List of Exiting COB LCD Modules:

Model	Content CharsXLines	Module size W x H(mm)	View area W x H(mm)	Dot size W x H(mm)	Character size W x H(mm)	Driving Method	Controller LSI or Equiv	IC Package	STN-TYPE	FSTN-TYPE
8D-C0802A	8X2	84.0X44.0	63.0X25.0	1.15X1.36	6.07X11.56	1/16	S6A0069	COB	Y	Y
8D-C0802B	8X2	58.0X32.0	38.0X16.0	0.56X0.66	2.95X5.56	1/16	S6A0069	COB	Y	Y
8D-C1202A	12X2	55.7X32.0	46.7X17.5	0.45X0.6	2.65X5.5	1/16	S6A0069	COB	Y	Y
8D-C1601A	16X1	80.0X36.0	64.5X13.8	0.55X0.65	3.2X5.95	1/16	S6A0069	COB	Y	Y
8D-C1601B	16X1	122.0X33.0	99.0X13.0	0.92X1.1	4.84X8.06	1/16	S6A0069	COB	Y	Y
8D -C1601C	16X1	80.0X36.0	64.5X13.8	0.6X0.7	3.2X8.2	1/11	S6A0069	COB	Y	Y
8D -C1601D	16X1	85.0X28.0	65.0X16.0	0.55X0.75	3.07X6.56	1/16	S6A0069	COB	Y	Y
8D -C1601E	16X1	80.0X36.0	64.5X13.8	0.55X0.75	3.07X6.56	1/16	S6A0069	COB	Y	Y
8D -C1602A	16X2	80.0X36.0	64.5X13.8	0.55X0.5	2.95X4.35	1/16	S6A0069	COB	Y	Y
8D -C1602B	16X2	122.0X44.0	99.0X24.0	0.92X1.1	4.84X9.66	1/16	S6A0069	COB	Y	Y
8D -C1602C	16X2	80.0X36.0	64.5X15.5	0.55X0.66	2.96X5.56	1/16	S6A0069	COB	Y	Y
8D -C1602D	16X2	84.0X44.0	64.5X15.5	0.55X0.66	2.96X5.56	1/16	S6A0069	COB	Y	Y
8D -C1602E	16X2	85.0X36.0	64.5X15.5	0.56X0.66	2.96X5.56	1/16	S6A0069	COB	Y	Y
8D -C1602F	16X2	72.0X36.0	64.5X15.5	0.56X0.66	2.96X5.56	1/16	S6A0069	COB	Y	Y
8D -C1604A	16X4	87.0X60.0	62.0X25.6	0.55X0.55	2.95X4.75	1/16	S6A0069	COB	Y	Y
8D -C2001A	20X1	116.0X37.0	83.0X18.6	0.6X0.65	3.2X5.55	1/16	S6A0069	COB	Y	Y
8D -C2002A	20X2	98.0X60.0	83.0X18.6	0.6X0.65	3.2X5.55	1/16	S6A0069	COB	Y	Y
8D -C2002B	20X2	116.0X37.0	83.0X18.6	0.6X0.65	3.2X5.55	1/16	S6A0069	COB	Y	Y
8D -C200C	20X2	146.0X43.0	123.0X23.0	0.92X1.1	0.98X1.17	1/16	S6A0069	COB	Y	Y

List of Exiting COG LCD Modules:

Model	Content (W X H)	Module size W x H(mm)	View area W x H(mm)	Dot size W x H(mm)	Dot pitch W x H(mm)	Driving Method	Controller LSI or Equiv	IC Package	STN-TYPE	FSTN-TYPE
8D -C2004A	20X4	98.0X60.0	76.0X25.2	0.55X0.55	2.95X4.75	1/16	S6A0069	COB	Y	Y
8D -C2004B	20X4	77.0X47.0	60.0X22.0	0.42X0.46	2.3X4.03	1/16	S6A0070	COB	Y	Y
8D -C2004C	20X4	146.0X62.5	123.5X43.0	0.92X1.1	4.84X9.22	1/16	S6A0069	COB	Y	Y
8D -C2402A	24X2	118.0X36.0	93.5X16.0	0.6X0.65	3.2X5.55	1/16	S6A0069	COB	Y	Y
8D -C2402B	24X2	208.0X40.0	178.0X23.0	1.16X1.16	6.0X9.63	1/16	S6A0069	COB	Y	Y
8D -C4001A	40X1	182.0X33.5	154.4X16.5	0.6X0.75	3.2X6.35	1/16	S6A0069	COB	Y	Y
8D -C4002B	40X2	182.0X33.5	154.4X16.5	0.6X0.65	3.2X5.55	1/16	S6A0069	COB	Y	Y
8D C4004A	40X4	190.0X54.0	147.0X29.5	0.5X0.55	2.78X4.89	1/16	S6A0069	COB	Y	Y
8D -G12232A	122X32	84.0X44.0	60.0X18.5	0.4X0.4	0.44X0.44	1/32	SED1520	COB	Y	Y
8D -G12232B	122X32	80.0X36.0	55.0X18.5	0.36X0.41	0.4X0.45	1/32	SED1520	COB	Y	Y
8D -G12232C	122X32	98.0X60.0	76.0X25.2	0.53X0.61	0.57X0.65	1/32	SED1520	COB	Y	Y
8D -G12232D	122X32	80.2X47.4	76.0X25.2	0.53X0.61	0.57X0.65	1/32	SED1520	COB	Y	Y
8D -G12864A	128X64	78.0X70.0	62.0X44.0	0.39X0.55	0.44X0.6	1/64	S6B0108A	COB	Y	Y
8D -G12864B	128X64	105.0X60.5	72.0X40.0	0.48X0.48	0.52X0.52	1/64	S6B0108A	COB	Y	Y
8D -G12864C	128X64	93.0X70.0	72.0X40.0	0.48X0.48	0.52X0.52	1/64	S6B0108A	COB	Y	Y
8D -G12864D	128X64	113.0X65.0	72.0X40.0	0.48X0.48	0.52X0.52	1/64	S6B0108A	COB	Y	Y
8D -G12864E	128X64	93.0X70.0	72.0X40.0	0.48X0.48	0.52X0.52	1/64	ST7920	COB	Y	Y
8D -G19264A	192X64	130X65.0	104.0X39.0	0.46X0.46	0.51X0.51	1/64	S6B0108A	COB	Y	Y
8D -G19264B	192X64	120X62.0	104.0X39.0	0.46X0.46	0.51X0.51	1/64	S6B0108A	COB	Y	Y
8D -G24064B	240X64	180.0X65.0	132.0X39.0	0.53X0.53	0.49X0.49	1/64	T6963C	QFP/COB	Y	Y
8D -G240128A	240X128	144X104	114X64	0.4X0.4	0.45X045	1/128	T6963C	QFP/COB	Y	Y

------------------------------------------------------------------------------------------------------------------------------------ Packaging & Shipping
Packaging & Shipping:

Packaging: Carton boxess, Cupboard , EPE, Blister Tray, About the package way, it is up to the size of products,
according to customer request and demand. Different countries have not same requirement..
Shipping: Express way as DHL,Fedex,EMS,UPS,air shipping,sea shipping,Any shipping method you prefer.



Payment Method:
FAQ
FAQ: I want the LCD display 8 digits and the outline size is 65x30x2.8mm...…?
Answer: No problem. Firstly, please kindly send us your specification/ drawing paper
If you have not the specification, you can also provide your samples; we will recommend the suitable one if it is standard products. Or we can customize for you based on your own requirement.
2.This LCD is just what we want, but it is big size, do you have any smaller size? And the display content need to be changed a little.
Answer: For the segment type LCD module, if you need modify the outline size or display content,
a new LCD glass module is need. We have to open new tooling for you.
3. This LCD display is HTN type, but I want STN type,can you make?
Answer: That's all right . we can change for you as per you request.
4. I want customize a new LCD module. Can you do?
Answer: Yes, we can. Please send your drawing paper. If you have not, please advise me the outline size
of the LCD display, display information( Glass thickness, Polarizer, Display Type, Connector mode,
Storage Temp. Operating Temp. Supply Voltage, Viewing direction, drive condition), we can customize for you.
5. What is leading time for tooling?
Answer: General speaking, it will cost 15 to 25 days after drawing paper confirmation and tooling charge payment,
we can report you the exact time when you confirm the drawing paper.
6. Can you send us samples for checking?
Answer: Yes,. Samples order is available.
7. What is the Leading Time?
Answer: If we have stock for the standard ones, the leading time is one day after payment. If it is the mass production for
special ones, the leading time is about 15-30 days. suppose we can finish earlier, we will report the information in advanced.

Our Services:
1. Free repair within one year after the shipment of products from us.
2. Replacement within 30 days after the shipment of products from us due to products' problems.
3. We can print your logo and stick your model No.on the cameras.
4. We have long cooperation with many shipping companies and our export volume is large. The shipping companies
can offer us good discounts.
5. Professional technician supports. We have a good after-sales service team. They can solve your problems in time.
6.All goods will be inspected and tested by our engineers and QC/QA before packing and shipment.
7.Customers satisfactory is most important to us.If you have any problem or questions regarding our transaction.Please contact us by Email or online. It will be responded within 24 hours.
8.Products pictures only for your reference. please kindly refer to the specification. we can provide the products basic on the specification. or you can offer your own specification or drawing , we can customize all kinds of LCD displays for you. thanks for your kind support always.


If you are interested in our products, Please feel free to contact us with below!
