Durable Design Grinding Machine with Permanent Magnet Chuck and Syntec CNC

Product Description

250/2550CNC Surface Grinding MachineThree Axies 250CNC Multifunction Grinding Machine Tool
At Cheng Yu Machinery Technology Co., Ltd., we embrace a philosophy of relentless advancement across our entire product line. We retain the discretion to enhance specifications, mechanics, or designs without prior notice or obligation, ensuring we stay at the forefront of innovation.

	parameter	unit	CNC-250	CNC-2550
general picture	Table size (x*y)	mm	200×500	250*500
	X axis travel	mm	580	580
	Y axis travel	mm	230	280
	Max center of wheel to table	mm	380	380
	Maximum load	kg	200	200
Table	Table T cell specification	mm×N	14×1	14×1
	Table speed	m/min	0-25	0-25
Y axis	Minimum feed	mm	0.001	0.001
	Single feed		0.1~10	0.1~10
	Fast moving speed	mm/min	0~1200	0~1200
Z axis	Minimum feed	mm	0.001/0.01	0.001/0.01
	Fast moving speed	mm/min	0~800	0~800
grinding	grinding wheel size max	mm	Φ200×Φ31.75×19
	grinding wheel speed	R.P.M	0~3600	0~3600
motor	spindle motor	HXP	2×2	2×2
	the Z axis motor	W	750	750
	the Y axis motor	W	750	750
	the X axis motor	W	1500	1500
	cooling motor	W	90	90
Size	height of machine	mm	2000	2000
	floor space	mm	2000×1350	2000×1450
	weight(about)	kg	1450	1550

Cheng Yu Machinery Technology Co., Ltd., proudly rooted in Dongguan City, Guangdong Province, draws from an impressive 30 years of Taiwanese expertise in grinding machine manufacturing. Our legacy is built upon the profound technological knowledge of our skilled team. In the vibrant world of CNC machine tools, the future is paved with high-speed, high-precision, composite, intelligent designs that are open, parallel-driven, networked, and environmentally conscious. These attributes define the innovative trajectory of CNC tools. Dongguan Chengyu Machinery Technology Co., Ltd. excels in crafting exceptional machine tools and accessories. Guided by our 'technology, innovation, reliable' ethos and a 'meticulous' commitment to quality, we engage deeply with our customers' processes and technological needs. Our comprehensive and scientific quality management system, coupled with state-of-the-art equipment, ensures product positioning that achieves unparalleled automation, precision, and quality. Responding to evolving market needs, Chengyu Machinery is at the vanguard of designing and manufacturing high-precision CNC surface grinding machines, CNC forming machines, and more. Our offerings also extend to industrial robots and fully integrated production solutions. Here is an overview of our CNC grinding machine series: I. HS Series: Models 618 / 250 / 3060 / 4080 / 40100, available in both servo and hydraulic configurations. Processing Capacity: Expertly handles surface grinding and grooving with precision. Patented Hydraulic Control System for supreme consistency (hydraulic models). Functionality: Features versatile grinding programs, including flat surface and groove cutting. Feed Mode: Customizable options for front, back, left, and right, with each grinding program retaining its specific feed mode memory. Safety Feature: Automatic shutdown triggered by grinding wheel overload. II. CNC Series: Offered in servo and hydraulic types for versatile applications. Processing Capacity: Excels in surface grinding, grooving, and complex scheduling tasks. Patented Hydraulic Control System ensures precision (specific to hydraulic models). Functionality: Comprehensive grinding programs cover surface, groove, sole, side, and complex displacement grinding. Advanced Wheel Dressing: Automatic cycle with rough and fine grinding adjustments, ensuring precise dressing and compensation. Feed Mode: Flexible front, back, left, and right configurations, with memory retention for each grinding program. Innovative Grooving: Capable of achieving both equidistant and non-equidistant grooving. 3. Four-axis CNC Grinding Machines: Available in horizontal and vertical configurations for varied applications. Processing Types: From arbitrary equal division to intricate skipping tooth processing. Customization: Enter waist circle and AB size for tailored solutions. Triangle Fillet: Input inscribed circle size B and fillet size R for precision. Quadrilateral Fillet: Provide side lengths A, B, and fillet size R for exact specifications. Eccentric Circle: Input eccentricity with start and end diameters for specialized tasks. Circle: Effortlessly specify both the starting and ending diameters for perfect circular creations. Arc: Simply input the arc size along with the rotation angle to achieve precise and beautiful curves. Step difference and rotation profile: Define these to ensure intricate and flawless machining results. Processing Schedule: Conveniently save your processing schedule as a file, making future sessions seamless and efficient.

---
