Basic Info.
Application
Fruit, Tomato
Portable Harvester Type
Pipe Rail
Application Field
Agriculture, Livestock, Aquaculture, Forestry, Greenhouse
Lift Mechanism
Scissor Lift
Hight
3.1m,3.5m,5.7m,6.5m
Specification
2300*750*2000mm
Production Capacity
200000/Year
Product Description
Product Description
A pipe rail trolley, often referred to as a greenhouse trolley, is a specialized piece of equipment used primarily in horticulture and agriculture to facilitate the movement of plants and materials along a system of rails or pipes. These trolleys enhance efficiency in greenhouses by allowing easy access to plants for maintenance, harvesting, and transport.
Key Features of Pipe Rail Trolleys: Rails/Pipes: Typically, these trolleys run on a system of parallel rails or pipes installed along the rows of plants in a greenhouse. Mobility: They can be manually operated or motorized, making it easier to transport heavy loads without causing strain. Adjustability: Some models allow height adjustment, which is particularly useful for tasks like pruning, harvesting, or inspecting plants at different levels. Material: Made from durable materials like steel or aluminum to withstand the humid environment of greenhouses and the constant movement. Capacity: Designed to carry substantial loads, ensuring that large quantities of plants or heavy equipment can be transported efficiently. Safety Features: Equipped with brakes or locking mechanisms to prevent accidental movement when stationary. Common Uses: Plant Transport: Moving plants between different sections of a greenhouse or from the greenhouse to the distribution area. Maintenance and Care: Facilitating tasks such as watering, pruning, pest control, and other plant care activities. Harvesting: Allowing workers to efficiently gather crops without excessive physical strain. Material Handling: Transporting soil, pots, fertilizers, and other materials used in greenhouse operations. Benefits: Efficiency: Streamlines various greenhouse operations, reducing the time and labor required for tasks. Ergonomics: Minimizes the physical strain on workers, reducing the risk of injuries. Space Utilization: Helps maximize the use of space within the greenhouse by providing a mobile work platform. Considerations: Compatibility: Ensure the trolley system is compatible with the specific layout and rail/piping system of your greenhouse. Maintenance: Regular maintenance is essential to keep the trolleys and rail system in good working condition. Customization: Depending on the specific needs, trolleys can be customized in terms of size, load capacity, and additional features like shelving or tool holders. In summary, pipe rail trolleys are invaluable tools in modern horticulture, significantly enhancing productivity and worker comfort in greenhouse environments.
Detailed Photos
Product Parameters
CHARACTERISTICS | |
Item No. | ZD-2000 |
Length | 2052mm |
Width | 736mm |
Height | 1979mm |
Platform Length | 2201mm |
Platform Width | 466mm |
Maximum Height | 3.1m |
Minimum Height | 648mm |
Battery | 2 x 12V / 230Ah |
Electric Motor Power | 0.5KW |
Weight | 480KG |
Body Material | Stainless steel |
Pipe Size | 48 & 51 mm |
Pipe Rail Type | Outside flange |
Rail Width | 55cm |
Simple Connected Charging | yes |
Hydraulic Platform | Auto Controlled |
Mechanical Side Movement | Manuel |
Company Profile
After Sales Service
1 Year Free Spare Parts Replacement
