CS6150 Precision Heavy Lathe Machine with Ce

US$7,900.00
1-4 SET
US$7,400.00
5+ SET

Basic Info.

Model NO.
CS6150
Guide Rail
Horizontal Guide Rail
Tool Holder
4-Statio Toolpost
Power Source
Electric
Controlling Mode
Artificial
Automatic Grade
Semiautomatic
Setting Mode
Floor-type
Precision
High Precision
Certification
CE, ISO 9001
Spindle Bore
82mm
Max. Swing Over Bed
500mm
Distance Between Centers
750/1000/1500/2000/3000mm
Machine
Lathe
Clour
Customer Appoint
Voltage
110V, 220V, 380V
Package Style
Fumigated Poly-Wood Case
Payment
T/T, Paypal, LC, West Union
Transport Package
Fumigated Poly-Wood Case
Specification
CE, SGS
Trademark
WMT
Origin
Chizhou, Anhui
HS Code
8458190000
Production Capacity
100 Per Sets Monthly

Packaging & Delivery

Package Size
238.00cm * 97.00cm * 123.00cm
Package Gross Weight
2050.000kg

Product Description

Feature:
Precision ground and supersonic frequency
The spindle system is high in rigidity and accuracy
The noise of the machine is low
Main specification :
Item Unit Parameter
CS6150
Machining range Maximum rotary diameter on the bed mm Φ500
Max. turning diameter on the saddle mm Φ300
Maximum workpiece length mm 3000
Spindle Spindle bore diameter mm Φ52
Spindle head type ISO 702/II No.6 bayonet type
Spindle speed r/min 24 levels 9-1600
Main motor power kW 7.5
Tailstock Diameter/maximum stroke mm φ75/150
Tailstock sleeve bore taper Morse 5
Tool holder Tool holder station/tool holder specification 4/25X25
Feed Max. travel in X direction mm 145
Maximum travel in Z direction m/min 320
X-feed range mm/r 93 types 0.012-2.73
Z feed range mm/r 93 types 0.028-6.43
Metric thread range mm 48 types 0.5-224
Inch thread range t.p.i 46 types 71-1/8
Modulus thread range πmm 42 types 0.5-112
Pitch thread range t.p.i. π 45 kinds 56-1/4
Other Cooling pump motor power kW 0.12
Rapid feed motor power kW 0.3
Machine size mm 4632*975*1270
Machine weight Kg 2900


Standard Accessories
Optional Accessories
3-jaw chuck (325mm) Quick change tool post
4-jaw chuck (400mm) Turning tools
Face plate Leadscrew cover
Steady rest Chuck guard
Follow rest Tool post cover
Splash guard Digital readout system
Stand Taper turning attachment
Halogen work lamp One piece casting stand
Toolbox & tools
Coolant system
Foot brake
Five position carriage stop

Machine photos:
