| BOM | Order Name | Description |
| 02353DAF | CR8PM1ABASC0 | NetEngine 8000 M1A Basic Configuration (Includes M1A Chassis, 1*IPU,Fixed Interface(4*10GE + 12*GE),2*DC Power,without Software and Document) |
| 02353DAG | CR8PM1ABASC1 | NetEngine 8000 M1A Basic Configuration (Includes M1A Chassis,1*IPU, Fixed Interface(4*10GE+12*GE),1*AC Power,without Software and Document) |
| 02353DAH | CR8PM1ABASC2 | NetEngine 8000 M1A Basic Configuration(Includes M1A Chassis,1*IPU, Fixed Interface(6*10GE+26*GE),2*DC Power,without Software and Document) |
| 02353EGG | CR8PM1ABASC4 | NetEngine 8000 M1A Basic Configuration(Includes M1A Chassis, 1*IPU,Fixed Interface(6*10GE+26*GE),1*AC Power,without Software and Document) |
| 02353JWJ | CR8PM1ABASC6 | NetEngine 8000 M1A Basic Configuration(Includes M1A Chassis,1*IPU, Fixed Interface(16*10GE+16*GE),2*DC Power,without Software and Document) |
| 02353JVU | CR8PM1ABASC8 | NetEngine 8000 M1A Basic Configuration(Includes M1A Chassis, 1*IPU,Fixed Interface(16*10GE+16*GE),1*AC Power,without Software and Document) |
| 88036KAT | CR8SM1U086C0 | NetEngine 8000 M1A basic configuration upgrade package (upgrade from 52G to 86G) |
| 88036KAW | CR8SM1U176C0 | NetEngine 8000 M1A basic configuration upgrade package (upgrade from 86G to 176G) |
| Item | NetEngine 8000 M1A |
| Dimensions (H x W x D) | 44.45mm×442mm×220mm (1U, Fixed box) |
| Switching Capacity(Bidirectional) | 352 Gbps |
| Forwarding Performance | 72 Mpps |
| Memory Size | 4G |
| Buffer size | 740MB |
| Power Input | DC:-40V to -72V; AC:100V to 240V |
| Typical Power Consumption | 75W |
| Port Capability | 16*10GE/GE/FE+12*GE/FE(o)+4*GE/FE(e) |
| L2 Feature | IEEE802.1q, IEEE802.1p, IEEE 802.3ad, IEEE 802.1ab, STP/RSTP/MSTP |
| L3 Feature | OSPFv2/V3, RIPv2, IS-IS/IS-ISv6, BGPv4/BGPV4+, IPv4 ACL/Telnet, 6VPE and Static routing protocol Dynamic ARP , static ARP, VLANIF interface and VxLAN |
| MPLS | LDP, RSVP-TE, Segment Routing(SR) MPLS, L2VPN(VPLS, HVPLS, and VLL), L3VPN, and seamless MPLS,MPLS-TP |
| SRv6/EVPN | Segment Routing IPv6(SRv6), EVPN L3VPN, EVPN VPWS, EVPN VPLS |
| VAS | NAT/CGN,IPSec |
| Multicast | IGMP v1/v2/v3, IGMP Snooping, Static multicast routing, PIM-SM/SSM, MBGP, NG-MVPN |
| QoS | 3 level H-QoS, CAR |
| ISIS | 512K |
| OSPF | 512K |
| IPv4 RIB | 512K |
| IPv6 RIB | 64K |
| IPv4 FIB | 512K |
| IPv6 FIB | 64K |
| MAC | 256K |
| ACL | 2048 |
| IPSec | 0.98Gbps (1400 Bytes) |
| Cache | 45 ms |
| Clock | 1588v2, Synchronous Ethernet clock |
| OAM | Telemetry,iFIT,BFD,NQA,RFC 2544,TWAMP |
| Operating temperature | -5ºC~45ºC |
