Rfm0.75kv 1000kvar 1000Hz Electrolytic Passive Component Water Cooling Capacitor for Funace

US$1,268.00-1,269.00 10 Pieces (MOQ)

Basic Info.

Model NO.
RFM 0.75-1000-1S
Packaging Type
Surface Mount
Capacitance
50-100uf
Structure
Fixed Capacitor
Manufacturing Material
Polypropylene
Electrolyte
Electrolytic
Usage
Low Frequency Coupling, Tuning, Filter, Low Frequency Bypass
Tuning
Polystyrene Capacitor
Filter
Composite Paper Capacitor
Compensate
Reactive Energy
Power Transformer
Prove Transmission Power Factor
Cooling Type
Cold Water
Using Range
Melting Furnace
Frequency
1000 To24000Hz
Case Material
Anti Rust Aluminum
Water Tube
Pure Copper
Warranty
3 Years
Market
High Frequency Device
Transport Package
Wooden
Specification
CE ROHS
Trademark
OEM
Origin
Zhejiang Yueqing
HS Code
85321000
Production Capacity
100000PCS/ Month

Packaging & Delivery

Package Size
70.00cm * 70.00cm * 60.00cm
Package Gross Weight
160.000kg

Product Description

Rfm0.75kv 1000kvar 1000hz electrolytic passive component Water Cooling Capacitor for funace
Series resonant capacitors: mainly used in high frequency induction heating equipment to increase power factor
or improve circuit characteristic, it also used in melting and casting equipment.
RFM0.75- - 1000 - 1 S
R=Electric heating
F=Liquid medium code (diarylethane)
M=Solid medium code (polypropylene film)
1000=1000KvarRepresents rated capacity (kVar)
1= 1000hzRepresents rated frequency (kHz)
S=Endnote number (water-cooled)
RFM water cooling capacitor Electric heating Capacitor specification
ite Specification Voltage Kvar Hz Rated UF A B h H weight
1 RFM40.25-500-3S 0.25 500 3 424.4 440 165 310 403 33
2 RFM20.375-160-8SB 0.375 160 8 22.64 303 120 200 293 13
3 RFM20.375-250-20S 0.375 250 20 14.15 303 120 175 268 11
4 RFM 0.375-750-1S 0.375 750 1 848.8 440 205 435 528 56
5 RFM20.5-400-40S 0.5 400 40 6.366 303 120 270 363 15
6 RFM20.5-640-20S 0.5 640 20 20.37 303 120 300 393 18
7 RFM50.65-1000-0.5S 0.65 1000 0.5 753.4 440 205 400 493 53
8 RFM30.65-1000-1S 0.65 1000 1 376.7 336 142 415 508 31
9 RFM30.65-1000-8S 0.65 1000 8 47.09 336 142 240 333 13
10 RFM20.75-160-8SB 0.75 160 8 5.659 303 120 200 293 12
11 RFM20.75-250-2.5S 0.75 250 2.5 28.29 303 120 200 293 12
12 RFM20.75-320-8S 0.75 320 8 11.32 303 120 200 293 12
13 RFM20.75-360-1S 0.75 360 1 101.9 303 120 240 333 14
14 RFM220.75-360-1S 0.75 360 1 101.9 303 120 270 363 15
15 RFM20.75-360-50S 0.75 360 50 2.037 303 120 200 293 12
16 RFM20.75-500-2.5S 0.75 500 2.5 56.59 303 120 220 313 13
17 RFM20.75-560-4S 0.75 560 4 39.61 303 120 240 333 14
18 RFM20.75-640-8S 0.75 640 8 22.64 303 120 175 268 11
19 RFM30.75-720-1S 0.75 720 1 203.7 336 142 270 363 19
20 RFM320.75-720-1S 0.75 720 1 203.7 336 142 310 403 23
21 RFM30.75-750-0.5S 0.75 750 0.5 424.4 336 142 515 608 38
22 RFM40.75-1000-0.5S 0.75 1000 0.5 565.9 440 165 400 493 42
23 RFM30.75-1000-1S 0.75 1000 1 282.9 336 142 360 453 26
24 RFM320.75-1000-1S 0.75 1000 1 282.9 336 142 410 503 31
25 RFM330.75-1000-1S 0.75 1000 1 282.9 336 142 450 543 33
26 RFM60.75-1000-1S 0.75 1000 1 282.9 336 165 375 468 33
27 RFM30.75-1000-2.5S 0.75 1000 2.5 113.2 336 142 270 363 19
28 RFM30.75-1000-8S 0.75 1000 8 35.37 336 142 220 313 18
29 RFM30.75-1000-30S 0.75 1000 30 9.431 336 142 240 333 19
30 RFM30.75-1500-1S 0.75 1500 1 424.4 336 142 515 608 38
31 RFM40.75-1500-1S 0.75 1500 1 424.4 440 165 350 443 40
32 RFM30.75-1500-2.5S 0.75 1500 2.5 169.8 336 142 340 433 24
33 RFM40.75-2000-1S 0.75 2000 1 565.9 440 170 400 493 41
34 RFM420.75-2000-1S 0.75 2000 1 565.9 440 170 465 558 48
35 RFM40.75-2000-6S 0.75 2000 6 94.31 440 165 240 333 26
36 RFM40.8-2000-1.5S 0.8 2000 1.5 331.6 440 165 350 443 40
37 RFM31.0-1000-1S 1 1000 1 159.2 336 142 360 453 26
38 RFM21.0-1000-20S 1 1000 20 7.958 303 120 240 333 14
39 RFM31.175-2000-2.7S 1.175 2000 2.7 85.39 336 142 350 443 25
40 RFM41.2-1000-0.5S 1.2 1000 0.5 221 440 165 325 418 33
41 RFM421.2-1000-0.5S 1.2 1000 0.5 221 440 165 360 453 41
42 RFM31.2-1000-1S 1.2 1000 1 110.5 336 142 300 393 22
43 RFM41.2-1200-0.7S 1.2 1200 0.7 189.5 440 165 300 393 30
44 RFM41.2-1500-0.5S 1.2 1500 0.5 331.6 440 165 465 558 44
45 RFM421.2-1500-0.5S 1.2 1500 0.5 331.6 440 165 495 588 50
46 RFM51.2-2000-0.5S 1.2 2000 0.5 442.1 440 205 435 528 56
47 RFM41.2-2000-1S 1.2 2000 1 221 440 165 360 453 40
48 RFM51.4-2000-0.5S 1.4 2000 0.5 324.8 440 205 425 518 55
49 RFM 1.5-1000-0.2S 1.5 1000 0.2 353.7 440 205 495 588 67
50 RFM3 1.5-1000-1S 1.5 1000 1 70.74 336 142 340 433 24
51 RFM3 1.5-2000-2.5S 1.5 2000 2.5 56.59 336 142 400 493 30
52 RFM3 1.6-1000-0.5S 1.6 1000 0.5 124.3 336 142 450 543 33
53 RFM 1.6-2000-0.5S 1.6 2000 0.5 248.7 440 205 390 483 52
54 RFM 1.6-3000-0.5S 1.6 3000 0.5 373 440 205 560 653 70
55 RFM 1.7-1500-0.25S 1.7 1500 0.25 330.4 440 205 610 703 78
56 RFM 1.7-3000-0.5S 1.7 3000 0.5 330.4 440 205 590 683 72
57 RFM 2.0-3000-4S 2 3000 4 29.84 440 165 350 454 38
58 RFM5 2.2-2000-0.5S 2.2 2000 0.5 131.5 440 205 435 539 56
59 RFM 2.4-2000-0.5S 2.4 2000 0.5 110.5 440 205 435 539 56
