Basic Info.
Plastic Type
Thermoplastic
Certification
CE, ISO9001:2008
Injection Weight (G)
1219 G
Screw Diameter (mm)
75 mm
Injection Rate (G/S)
358 G/S
Ejector Stroke(mm)
180 mm
Product Description
Product Description
Specification
DESCRIPTION
|
| UNIT
| BJ330-V6/S6
|
LAMPING UNIT
| Clamping force
| KN
| 3300
|
| Opening stroke
| mm
| 600
|
| Max.datlight
| mm
| 1300
|
| Platen size
| mm
| 985*985
|
| Space between bars
| mm
| 670*670
|
| Max.mold height
| mm
| 700
|
| Min.mold height
| mm
| 300
|
| Ejector stroke
| mm
| 180
|
| Ejector force
| KN
| 77
|
INJECTION UNIT
| Screw diameter
| mm
| 68
|
| Screw L/D Ratio
| L/D
| 21
|
| Injection Pressure
| MPa
| 169
|
| Shot volume
| cm3
| 1126
|
| Shot weight (ps)
| g
| 1005
|
|
| oz
| 35.4
|
| Injection rate
| g/s
| 328
|
| Screw stroke
| mm
| 310
|
| Screw speed
| rpm
| 193
|
POWER UNIT
| Hydraulic system Pressure
| MPa
| 17.5
|
| Pump motor power
| KW
| 37/50
|
| Heater power
| KW
| 18
|
GENERAL
| Oil tank capacity
| L
| 460
|
| Machine weight
| T
| 11
|
| Machine dimensions (L*W*H)
| m
| 6.8*1.62*2.3
|
Company Profile
Q1: Are you a manufacturer or trading company?
A1: We are a factory for plastic machines. Over 24 Years Experience In Manufacturing Injection Molding Machine And Blow Molding Machine.
Q2: Delivery time
A2: Normally Machine Delivery from the factory in 0-60 days after receiving the down payment. (During Chinese Public Holidays like National Day or Chinese New Year, the delivery time should be 10-30 days longer accordingly).
Q3: Where is your factory located?
A3: Our factory is located in No.5 Chuangxin Xi Road, Leping Town, Sanshui District, Foshan City, Guangdong Province, China. 1h drive from Guangzhou to our factory. Welcome to visit our factory.
>>
