| Display Pane | Brand | TKUN |
| Size/Proportion | 19 inch 5:4 | |
| Model | TK190XGA | |
| Brightness | 450cd/㎡（optional 1000cd/㎡) | |
| Resolution | 1280*1024 | |
| Contrast | 1000:1 | |
| Display color | 16.7M | |
| Response time | 2-5ms | |
| Visible angle | 85/85/85/85 | |
| Pixel pitch(mm) | 0.294(H)X 0.294(V) | |
| Touch screen | Touch type | Projected multi-point capacitive touch screen (10 points) |
| Touch screen hardness | 3H | |
| Positioning accuracy | less than 2MM | |
| Ct.Life | ≥50 million times | |
| Touch media | Capacitive Touch Pen, Fingers | |
| Right click functionality | click on a point, long and hold more than 3 seconds | |
| Touch interface | USB(optional COM) | |
| Support system | win7, win8, win10, android, linux and so on | |
| Motherboard Function | Refresh frequency | 60Hz |
| Power input | DC12-36V | |
| Functional interface | HD，DP，VGA，Audio | |
| Environmental parameters | Operating temperature/humidity | -10℃ to +60℃/ 0-80% relative humidity, no condensation |
| Storage temperature/humidity | -15℃ to +65℃/ 0-90% relative humidity, no condensation | |
| Product Service | After service | one-year warranty and lifelong maintenance |
| Customized service | OEM/ODM is available for material, appearance, dimensions, wide temperature, outdoor highlight, wide voltage, etc. |
