Automatic 3 Die 6 Blow for Screw Production Line

Product Description

High-speed automatic Multi-stage /station cold Heading Machine

Product Specification:

Model description	Die quantity	blow quantity	Max cut-off diameter	Max cut-off length	Main die	punch	Cut-off die	Main motor	Pump motor	stress	size	Out put	NET WEIGHT
2415L	2	4	7	55	46*100	31*85	19	5HP	1/4HP	15TON	195*110*115	60-100	2300
3615L	3	6	7	55	46*100	31*85	19	5HP	1HP	15TON	230*126*140	50-80	3100
3625L	3	6	12	100	58*100	38*105	32	10HP	1HP	40TON	315*175*162	40-65	8000
3610	3	6	5	35	34.5*80	24*60	19	2HP	1/4HP	10Ton	165*100*100	60-100	2000
3615L	3	6	7	55	46*100	31*85	19	5HP	1HP	15Ton	230*126*140	50-80	3100
3625L	3	6	12	100	58*150	38*105	32	10HP	1HP	40Ton	315*175*162	40-65	8000
3630	3	6	16	150	80*200	50*120	40	20HP	1HP	65Ton	430*200*185	40-50	13000
3640	3	6	20	200	80*250	58*150	45	30HP	1HP	90Ton	451*265*200	30-50	18000
2410	2	4	5	35	34.5*70	24*60	19	2HP	1/4HP	10Ton	165*100*100	80-120	1200
2415S	2	4	5	35	46*85	37*70	19	3HP	1/4HP	15Ton	195*110*115	60-100	2200
2415L	2	4	7	55	46*100	31*85	19	5HP	1/4HP	15Ton	195*110*115	60-100	2300
2420	2	4	7	45	50*97	31*80	28	5HP	1/4HP	20Ton	260*137*140	50-70	3900
2425	2	4	10	75	58*127	38*100	32	7.5HP	1/4HP	25Ton	305*154*162	40-65	5250
2425L	2	4	12	100	58*150	38*105	32	10HP	1HP	25Ton	305*154*162	40-65	6500
2430	2	4	13	100	80*150	50*120	40	15HP	1HP	65Ton	400*185*185	40-50	10000
2440	2	4	15	150	80*220	58*150	45	25HP	1HP	80Ton	451*210*200	35-50	14200
5B4S	4	4	3	35	30*50	25*55	19*30	5HP		10Ton		150-250	2600
7B4S	4	4	5	40	46*100	31*80	19*35	10HP		20Ton		150-250	4500
10B4S	4	4	8	60	50*100	40*80	28*46	15HP		40Ton		150-200	8000

Product Picture:
Dongguan Haoyijia machine is a professional company, focusing on manufacturing automatic combination machines, such as full automatic washers and Screws Assembly Machine (spring washer machine and meson machine ),Cold Header Machine, Thread Rolling machine and Sorting Machine ect.
Over years' R&D, our products are achieving to the top level in China, so we could meet all customers' requirement,any interesting,pls don't hesitation to contact us now.
Why choose us
1. Create value for our valuable customers
we always provide good quality and nice design products to meet the needs of the customers, we are the leader in this field and we always provide good products and service to our valuable customers.
2. Better quality and service with lower price
we always supply the better price on the same quality level, and try our best to save the client's every cent.
3. Dare to innovation.
Every year, our company will develop the new products to meet the market need.
FAQ
Q: what's the packing of the machine?
A.In wooden pallet, In plastic film, the spare parts and cabinet packed by wooden box.
Q: What's the payment term?
A.Usually by T/T ( 30% in advance, the balance shoud be paid shipping before)
Q: Can I change the motor as my local voltage?
A.We can change the voltage as your requirement, and there's no extra charge.
Q: How do your control quality?
A.W have an inspection team to check the products at all stages of the production process.
Q:What parameter is necessary?
A.The nail diameter, nail length ect are mainly needed, detailed information would be appreciated, Special requirement can be discussed.
Q:How long will it take to deliver goods?
A:We will deliver the goods within 10 days for spare parts, other goods maybe take a little more times to test and prepare, we will deliver the goods within the deadline which both parties agreehainiud. Delivery& Packing

Dongguan Haoyijia Machine will do the best to provide the best quality products and first-class service to the customers,looking forward to cooperating with you~

---
