Basic Info.
Type
Injection Blow Molding
Plastic Type
Thermoplastic
Plasticizing Way
Screw Type
Computerized
Computerized
Certification
CE, ISO9001:2008
Product Name
Injection Molding Machine
Function
Multifunctional Plastic Products Making
Motor
Servo Energy Saving
Machinery Size
12.38m*2.8m*3.5m
Advantage
Energy Saving,Long Service Life
Application
Plastic Products
Clamping Force(Kn)
320 Ton
Production Capacity(Sets)
1000
Feature
Stable Quality, Competitive Cost, Careful Service
Quality
Professional Quality Control Team
Transport Package
Woollen Case
Specification
12.38m*2.8m*3.5m
Production Capacity
1000PCS/Hr
Product Description
Fully Automatic Cheap PC Plastic Electric LED Light Bulb Lamp Cover Body Making Manufacturing Injection Blow Moulding Machine
Product Description
SINO-TECH ST-320SEIII injection molding machine is designed for plastic dustbin, chairs, car bump pallet etc. It is with demoulding linkage which shorten the plastic parts cycle time. ST-320SEIII with high speed, stable performance and it is energy-saving. Our customers can get higher production with same labor and cost.
Main Features
1. 30% higher energy saving than using traditional variable pump.
2. Stable and smooth movement supported by AC servo motor.
3.Effective reduction of energy consumption due to reduced oil.and cooling water attained by hydraulic system.
4. High performance European B&R control system.
We are professional plastic injection molding machine manufacturer for all kinds of plastic products, Clamping force from 70 to 4000Ton, injection weight from 50 to 10000g. Also we have CE and ISO certification.
Product Parameters
Item | | 320SElll |
| | 3200-1930 |
Screw diameter | mm | 60 | 65 | 75 |
Theoretical shot volume | cc | 919 | 1078 | 1436 |
Shot weight (PS) | g | 836 | 981 | 1307 |
Shot weight (PS) | oz | 29.5 | 34.7 | 46.2 |
Length/Diameter ratio | L/D | 22.5 | 20.8 | 18 |
Injection pressure | MPa | 210 | 179 | 134 |
Injection rate | cm³/sec | 306 | 359 | 477 |
Injection stroke | mm | 325 |
Max. Screw speed | rpm | 224 |
Plasticizing capacity (PS) | g/s | 49.3 | 55.4 | 77.9 |
Injection unit force | Ton | 9.1 |
Carriage stroke | mm | 350 |
Clamping force | Ton | 320 |
Max. daylight | mm | 1400 |
Clamping stroke | mm | 700 |
Distance btwn. Tie bars | mm | 680*680 |
Min mould dimension | mm | 470*470 |
Mould thickness range | mm | 250-700 |
Ejector force | Ton | 11.1 |
Ejector stroke | mm | 200 |
No. of ejector pins | unit | 13 |
Max. motor power | kW | 40.9 |
System pressure | MPa | 17.5 |
Hydraulic pump capacity | L/min | 220 |
No. of heater zones | unit | 5+1 |
Heater input power | kW | 22.15 |
Ultimate capacity | kw | 64.05 |
Current | A | 87.6 |
Net weight | Ton | 11.52 |
Oil filling capacity | L | 550 |
Seller Recommendation
Detailed Photos
Application
Company Profile
FAQ
1. who are we?We are based in Jiangsu, China, start from 2011,sell to North America(30.00%),South America(20.00%),Western Europe(16.00%),Oceania(10.00%),Mid East(10.00%),Eastern Europe(5.00%),Southeast Asia(5.00%),Africa(4.00%). There are total about 5-10 people in our office.2. how can we guarantee quality?Always a pre-production sample before mass production;Always final Inspection before shipment;3.what can you buy from us?Extrusion Blow Molding Machine,Pet Blow Molding Machine,IBC Cage Production Line,Plastic Extrusion Line,Waste Plastic Recycling And Pelletizing Line4. why should you buy from us not from other suppliers?Our company have the strict system from the material purchase,machine part processing and inspect. We have the detailed Assemble prcess according to the machine Assemble structure. We test not one time before the machine delivery to the customer factory.5. what services can we provide?Accepted Delivery Terms: FOB,CFR,CIF,EXW,Express Delivery;Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;Accepted Payment Type: T/T,L/C,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian
>>
