Soft Plastic Ocean Sea Ball Blowing Mould Children Toy HDPE Kids Ball Extrusion Blow Molding Machine

US$25,000.00-30,000.00 1 Piece (MOQ)

Basic Info.

Model NO.
ysd
Raw Material
HDPE
Making Method of Parison
Extrusion-Blow Molding
Automation
Automatic
Computerized
Computerized
Certification
CE, ISO9001:2008, Ysd
After-sales Service
24 Hours
Machine Type
High Speed Plastic Bottle Making Machine
Control Mode
PLC
Motor Power
11kw
Clamping Force
1600kN
Blow Moulding Type
Extrusion Blow Moulding
Auto Deflashing
Available
Output(Dry Cycle)
750 PC/Hr;
Die Head Option
Single, Double, Tri-Head, Tetra-Head
Production Usage
Bottle, Toy, etc
Max Container Capacity
250L
Transport Package
Wooden Case
Specification
2800*1800*2000mm
Trademark
YSD
Origin
China
Production Capacity
500

Packaging & Delivery

Package Size
526.00cm * 361.00cm * 366.00cm
Package Gross Weight
1800.000kg

Product Description

Product Parameters

Production capacity
350pc/h
Screwed diameter
65mm
Screwed diameter ratio
1:25L/D
HDPE Max Output
40kg/h
Material cutting method
Hot knife
Max mold size(L×W×H)
220×300×380mm
Blowing pressure
0.4-0.6Mpa
gas consumption
0.5m3/min
Power of mechanical and electrical extruder
11KW
Heating power of extruder
10KW
Total power
23KW
Dimension mm(L X W X H)
2800*1800*2000mm
Weight
2.0T
Control type
PLC PC Control
Suitable material
PE/PP

Product Description

Detailed Photos

Die heads are used for extruding material tubes. The number of die heads can be selected according to the size of the product and therequired output.
Hydraulic cylinder that moves the mold. The whole machine has hydraulic control, making production and use more stable.
PLC touch screen, machine operation iscontrolled by PLC, easy to operate. PLC language can be selected upon request
Electrical system, including circuit switches,frequency converters and servo controllers of theentire machine
The screw is used to heat raw materials and is equipped with a heating coil. After the raw materials enter the screw, they are heated and flow into the die.

After Sales Service

Clients visit

Company Profile

FAQ

1.How can i get the price?
We usually quote within 2 hours after we get your inquiry (Even in weekend and holidays,we are still
trying to approach you at earliest). If you are very urgent to get the price, please call us or contact us in other ways so that
we can offer you a quote.
2.Do you have stock ?
Most of machines we have stock,we execute 24 hours dispatch rules.
3.What is your lead time?
It depends on the order quantity .But 10 days are the maximum.
4.What is your payment term?
T/T,Western Union,MoneyGram,and Paypal.This is negotiable.
5.Do you accept trade assurance ?
Yes, we accept.
6.Can I get the shipping freight from you ?
Yes, we can help to ask the best reasonable prices.
7.What is the shipping method?
It could be shipped by sea,by air or by express(EMS,UPS,DHL,TNT,FEDEX and ect).Please confirm with us before placing orders.
8.How do you make our business long-term and good relationship?
a. We keep good quality and competitive price to ensure our customers benefit ;
b. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come
from.
