Basic Info.
Application Field
Agriculture
Farming Policy
Dry Cultivating Machinery
Operation
Soil Preparation Machinery, Continuous Running Operation
Arbor Configuration
Horizontal Axis
Transport Package
Standard Export Packaging
Specification
1300*400*400
Product Description
Parameter
Model | Matched power(hp)
| Working width(cm)
| Working depth(cm)
| No of knives
| Type of knife
| Total weight (kg)
| O.D.mm (L*W*H) |
1GQN/GN-90 | 15-20 | 90 | 10 to 18 | 20 | IT-225 | 175 | 900*700*700 |
1GQN/GN-110 | 18-22 | 110 | 10 to 18 | 24 | IT-225 | 180 | 1050*700*700 |
1GQN/GN-125 | 20-25 | 125 | 10 to 18 | 28 | IT-225 | 195 | 1360*700*700 |
1GQN/GN-140 | 25-30 | 140 | 10 to 18 | 32 | IT-225 | 200 | 1490*700*700 |
1GQN/GN-150 | 25-30 | 150 | 10 to 18 | 36 | IT-225 | 210 | 1590*800*800 |
1GQN/GN-160 | 30-50 | 160 | 10 to 18 | 40 | IT-225 | 230 | 1690*800*800 |
1GQN/GN-170 | 30-50 | 170 | 10 to 18 | 44 | IT-225 | 230 | 1650*800*800 |
1GQN/GN-180 | 50-60 | 180 | 12 to 20 | 52 | IT-245 | 350 | 2010*800*800 |
1GQN/GN-200 | 55-75 | 200 | 12 to 20 | 60 | IT-245 | 380 | 2100*800*800 |
1GQN/GN-220 | 60-80 | 220 | 12 to 20 | 50 | IT-245 | 400 | 2303*800*800 |
1GQN/GN-230 | 60-80 | 230 | 12 to 20 | 50 | IT-245 | 420 | 2410*800*800 |
1GQN/GN-250 | 75-80 | 250 | 12 to 20 | 72 | IT-245 | 450 | 2600*800*800 |
1GQN/GN-280 | 80-160 | 280 | 12 to 20 | 72 | IT-245 | 490 | 2950*800*800 |
1GQN/GN-300 | 90-160 | 300 | 12 to 20 | 80 | IT-245 | 600 | 3150*900*900 |
1GQN/GN-350 | 125-180 | 350 | 12 to 20 | 88 | IT-245 | 890 | 3650*950*950 |
Shandong Ling Ke Industry Group Co., Ltd. Introduces We are Factory, We are Manufacturer, We are Producer.We guarantee all tractor part we use is high quality.We have detailed Tractor parts manual, maintaince manual and operation manual.Any quality problems occur during the warranty time, we will provide tractor parts for free.(We have to admit that we only produce high-quality tractors, we focus on the quality of our tractor parts and the superb skills of our assembly workers, so if you only focus on the price but not the product quality and after sales service, we cannot serve you.)All of our tractor components: front axle, rear axle, gearbox assembly, clutch, fuel tank, tires, lift cylinder, battery and all other parts are the best brand. (All tractor psrts are tested for cleanliness before assembly)
We would like to thank you for your interest in our tractor. We are a full service tractor company, able to meet all of your construction tractor needs. We are in Weifang city, Shandong Province. Our organization is composed of many skilled team members who can - with regards to tractor - guarantee the success of your endeavor.
We look forward to the opportunity of serving all your tractor needs
>>
