US$7,000.00-11,000.00
|
1 Piece
(MOQ)
|
Basic Info.
Technical Class
Pulse Laser
Applicable Material
Metal
Structure Type
Gantry Type
Laser Classification
Free Electron Laser
Laser Technology
Laser Vapor Cutting
Product Name
Steel Sheet Laser Cutting Machine
CNC Machine
CNC Laser Cutter Machine
Portable Machine
Portable Laser Machines
Machinery
Manufacturing Processing Machinery
Laser Head
Raytools Laser Torch
Mode of Operation
Continuous Wave
Positioning Mode
Red Light
Cooling Mode
Water Cooler
Structure
Gantry Portable X,Y Axis
Selling Point
Cheaper Price Laser Cutter
Material Type
Metal Sheet
Transport Package
Wooden Case
Packaging & Delivery
Package Size
361.00cm * 180.00cm * 100.00cm
Package Gross Weight
600.000kg
Product Description
Introducing our new portable laser cutting machine!
With small packing size and lower cost, our portable fiber laser cutter is your best option!
Specification Chart
Features for 1500W 2000w 3000w Portable Fiber Laser Cutting Machines
1.Low cost,laser power consumption only 0.5-1.5kw per hour. 2.China best quality laser source,high performance,stability and service lifespan over 100,000hours,free of maintenance.High speed ,high efficiency,thin plate cutting can be over 10 meters per minute. 3.Automatic height sensor on laser head for uneven pieces. 4.Imported ball screw and linear guide rail driving system. 5.Easy and efficient CNC software for fast programming.
No. | machine model:ALLWIN-1530-3000W |
1 | max working area | 1500mmx3000mm |
2 | Packing dimension | 2000mmx3000mmx1700mm |
3 | Laser source | 3000W 2000W 1500W MAX LASER SOURCE |
4 | laser head | Swiss RAYTOOLS with auto focus |
5 | software | Professional FSCUT2000 with Cypcut software |
6 | motor and driver | invance servo motor driver |
7 | Reducer | SHIMPO reducer |
8 | Water chiller | S&A brand with Dual temperature,dual control |
9 | Rack and pinion | Taiwan brand T-WIN rack and pinion |
10 | Guild rails | HIWIN GUILDER RAIL |
11 | Exhaust fan | Blower Exhaust fan |
13 | Air compressor | YES |
14 | voltage stabilizer | YES |
15 | Accessories included | 1 SET RAYCUS FIBER LASER SOURCE 2000W |
1 SET RAYTOOLS LASER HEAD(AUTOMATIC FOCUS) |
1 SET WATER CHILLER |
CYPCUT SOFTWARE |
INDUSTRIAL COMPUTER |
FAN |
LASER PROTECTION GLASSES |
FIBER LASER CUTTING BED |
ATTACHED RAYTOOLS LASER TORCH:
High-quality and accurate cuts,
Auto-focus capabilities,
Height sensing technology,
Collision protection
ATTACHED HANLI WATER CHILLER :
Maintain precise and stable temperatures
Space-saving
Low Maintenance Requirements
ATTACHED MAX LASER SOURCE
Good beam quality
Small and sturdy,
Built-in cooling fan
...
X-AXIS PULLY AND RACK
Smooth Operation
Compact Design
High Precision
CNC OPERATION DISPLAY SCREEN
Real-time monitoring, precise control, error detection, job management, integration with CAD/CAM software...
Metal cutting samples
With cutting error less than 0.56mm
Carbon steel 1.5mm cutting effect..using 1500w power
Carbon steel 6mm cutting effect..using 3000w power
Other Laser Cutting Machines Recommeded
Warranty for the machine
1. Two years quality guarantee for the main parts of the machine, excluding consuming parts, and the main parts shall be changed free of charge during the warranty time 2. Lifelong maintenance for the machine, and lifelong technical support from sophisticated English-speaking engineer team. 3. Free training course at our plant 4. We will provide the machine consuming parts with factory price when you need replacement. 5. 12 hours online service each day, free technical support. Packaging & Shipping
Package and delivery the fiber laser cutting machine
1.Anti-collision package edge: All parts of the machine are covered with some soft materials, mainly the use of pearl wool .
2.Fumigation wooden box:Our wooden box is fumigated, do not need to check the wood, saving the transport time.
3.Whole film packaging machine: Avoid all damage that may occur during delivery. Then we will cover the plastic package tightly to ensure that the soft material is covered intact, also avoiding water and rust.
The outermost is a wooden box with a fixed template.
4.Wooden box at the bottom of a solid iron socket for easy handling.
Company Profile
About us:
1-Brands and variety of consumables:
We are producing replacements of Hypertherm, Lincoln, kaliburn, Thermal Dynamics, P80 and Chinese brands, including plasma electrode, plasma nozzle, swirl ring, plasma shield and retaining cap.
We use high-quality hafnium wire to ensure long service life and good cutting effect. Our product is affordable and can also ensure excellent performance.
2-Machines:
We have been specialized in CNC equipment and laser equipment more than 10 years. We can provide you products with high quality and low price. Our products include CNC plasma cutter, fiber laser cutter, laser welding machine, laser cleaning machine as well as related consumable material.
3- Business philosophy:
We want to build long-term relationships with customers rather than developing one-off deals.
By providing our products to help you succeed in your endeavors.
The core idea of ALLWIN is our commitment to achieving mutual success for our customers, shareholders, and employees through collaboration.
4-We are sure that one of our products is that you are looking for. We also welcome you to visit our factory!
>>
