Three Axies 250CNC Precision CNC Grinding Machine for Quality Assurance

Product Description

250/2550CNC Surface Grinding MachineThree Axies 250CNC Multifunction Grinding Machine Tool
At Cheng Yu Machinery Technology Co., Ltd., we pride ourselves on a steadfast commitment to perpetual enhancement of our entire product line. Our policy allows us the flexibility to refine specifications, mechanics, or designs at our discretion, ensuring our offerings remain at the cutting edge of innovation, all without prior notification or obligation.

	parameter	unit	CNC-250	CNC-2550
general picture	Table size (x*y)	mm	200×500	250*500
	X axis travel	mm	580	580
	Y axis travel	mm	230	280
	Max center of wheel to table	mm	380	380
	Maximum load	kg	200	200
Table	Table T cell specification	mm×N	14×1	14×1
	Table speed	m/min	0-25	0-25
Y axis	Minimum feed	mm	0.001	0.001
	Single feed		0.1~10	0.1~10
	Fast moving speed	mm/min	0~1200	0~1200
Z axis	Minimum feed	mm	0.001/0.01	0.001/0.01
	Fast moving speed	mm/min	0~800	0~800
grinding	grinding wheel size max	mm	Φ200×Φ31.75×19
	grinding wheel speed	R.P.M	0~3600	0~3600
motor	spindle motor	HXP	2×2	2×2
	the Z axis motor	W	750	750
	the Y axis motor	W	750	750
	the X axis motor	W	1500	1500
	cooling motor	W	90	90
Size	height of machine	mm	2000	2000
	floor space	mm	2000×1350	2000×1450
	weight(about)	kg	1450	1550

Cheng Yu Machinery Technology Co., Ltd. is a beacon of excellence, founded in Dongguan City, Guangdong Province. Drawing from an impressive 30-year legacy of grinding machine expertise from Taiwan, we are a powerhouse of technical prowess and industry knowledge. The CNC machine tool industry is galloping forward, embracing trends of high-speed, high-precision innovations. The future is characterized by composite systems, intelligence, open structures, parallel drive mechanisms, networking, and a commitment to green initiatives—heralding the next era of advancement. Dongguan Chengyu Machinery Technology Co., Ltd. stands at the forefront of machine tool production and processing. With a steadfast dedication to 'technology, innovation, and reliability,' we commit to our 'meticulous' quality policy to deliver top-tier products and stellar customer service. By studying our customers' processes and requirements meticulously, we innovate relentlessly to elevate product applicability, nurturing the growth of the numerical control industry. Our vision is clear: to achieve unparalleled automation, precision, and quality, supported by an impeccable quality management system, cutting-edge equipment, and world-class expertise. In a dynamic market landscape, Chengyu Machinery excels in crafting high-precision CNC equipment, including surface grinding machines, CNC forming machines, four-axis punch grinders, vertical slider grinders, and gantry rail grinders. Our scope extends to designing industrial robots, automated production lines, and integrated applications, showcasing our prowess in technological innovation. Here's an overview of our CNC grinding machine series: I. HS Series 618 / 250 / 3060 / 4080 / 40100 (Servo Type / Hydraulic Type) Processing Capacities: Delivering excellence in surface grinding and precise grooving. Our patented hydraulic control system sets the standard for precision and reliability (Hydraulic Type). Functionality: Dive into advanced grinding programs offering flat surface refinement and groove cutting precision. Feed Mode: Customize your process with selectable front, back, left, or right feed modes, storing preferences for each program. An intuitive system halts the grinding wheel in case of overload, ensuring optimal safety and efficiency. II. (Servo Type / Hydraulic Type) Processing Capabilities: Master the art of surface grinding, grooving, and sophisticated scheduling. Patented Hydraulic Control System: Unleash superior control and precision (Hydraulic Type). Functions: Equip yourself with diverse grinding programs for surface finesse, groove carving, sole and side grinding, along with complex displacement grinding. Grinding Wheel Dressing: Automate the dressing process with settings for rough and fine grinding, featuring auto-compensation within grinding cycles. Feed Mode: Choose from front, back, left, or right, each program memorizing your preferred feed mode for consistency. Achieve precision with equidistant grooving or tackle the challenge of non-equidistant, varied-depth grooving. 3. Four-Axis CNC Grinding Machines: Available in versatile horizontal and vertical models. Processing Types: Seamlessly perform arbitrary equal division and intricate skipping tooth processes. Waist Circle: Input dimensions AB to achieve desired curvature. Triangle Fillet: Define your design by inputting inscribed circle size B and fillet radius R. Quadrilateral Fillet: Specify side lengths A and B with fillet radius R for precision crafting. Eccentric Circle: Input eccentricity along with starting and ending diameters to achieve complex shapes. Create perfect circles effortlessly by entering your desired starting and ending diameters. Experience precision like never before. Craft beautiful arcs with ease by simply inputting the arc size and rotation angle. Achieve flawless curves with unmatched precision. Seamlessly manage step differences and rotation profiles with our advanced technology, ensuring superior results every time. Effortlessly save your processing schedule as a file for quick and easy access in future operations, enhancing efficiency and convenience.

---
