800 W Wind Turbine Generator 12 V 24 V 48 V, 6-Blade Horizontal Wind Power Generator with MPPT Charge Controller Custom Power
US$199.00
10 Pieces
(MOQ)
Basic Info.
Model NO.
FXZ6001
Output Type
AC Three Phase
Number of Blade
6 Blades
Rotating Shaft
Horizontal
Stress Way of Blade
Lift Force
Power
＜10kW
Phase
3
Certification
CE, ISO, SGS
Rated Power
800W
Maximum Wind Speed (M/S)
40
Blade Material
Nylon
Package Including
Wind Generator, MPPT
Transport Package
Paper Case
Trademark
Bailihao
Origin
China
Packaging & Delivery
Package Size
67.00cm * 28.00cm * 21.00cm
Package Gross Weight
10.000kg
Product Description
Product description Technical data: Rated power (W): 800 W. Maximum power (W): 800 W. Rated voltage (V): 12 V / 24 V / 48 V. Rotor blade length (mm): 580. Total weight (kg): 10. Rotor diameter (m): 1.3. Nominal wind speed (m/s): 13 m/s. Starting wind speed (m/s): 1.3. Maximum wind speed (m/s): 40 Generator: 3-phase permanent magnet synchronous generator. Lifespan: over 20 years. Bearing: HRB or customized according to customer requirements. Blade material: nylon. Case material: aluminium alloy. Permanent magnet: rare earth NdFeB. Control system: electromagnetic control. Lubrication: high-performance grease. Operating temperature: -40°C to +80°C. Package contents: 1 x wind turbine generator. 6 x rotor blades. 1 x charge controller. 1 x user manual (English language not guaranteed). Includes mounting accessories.
