PP886H 3BSE069297R1 ABB Touch screen operation panel
PP886H 3BSE069297R1 ABB Touch screen operation panel
Our Email: 2235954483@qq.com
contact number:13313705507
contacts：HE
Panel PP886R PP887H PP887S
Article number 3BSE092985 3BSE092986 3BSE092987
Display size 15.4" 15.4" 15.4"
Display resolution, ratio 1280 x 800 (16:10) 1280 x 800 (16:10) 1280 x 800 (16:10)
Display colors TFT LCD
Brightness (cd/m2) 450 1000 1000
Dimming Maritime optimized down to 0.5 cd/m2
Interaction type Resistive touch
Processor ARM9 (800 MHz) ARM9 (1 GHz) ARM9 (1 GHz)
Main memory 1 GB 2 GB 2 GB
Application memory 1,5 GB (SSD) 3,5 GB (SSD) 3,5 GB (SSD)
External storage media 1 × SD card slot (or SDHC with latest image loaded)
Realtime clock Yes
Ethernet (shielded RJ 45) 1 × 10/100 Base-T 2 x 10/100 Base-T 2 x 10/100 Base-T (4 pin M12)
USB 2 × USB 2.0, max 500mA
Serial port 1 × RS232, 1 × RS422/485 1 xRS232, 1 x RS422/RS485, 1 x RS485
Dimension W×H×D (mm) 410 x 286 x 73 410 x 286 x 65
Cut-out dimension W×H(mm) 394 x 270
Mounting depth mm[1] 66 (166) 66 (166) The sealed model is mounted on
a VESA bracket or similar and therefore
the mounting depth is the same
as dimensions.
Mounting Panel Mount
Net weight (kg) 4.1 4.1 4.8
Frame material Gray powder-coated aluminum
Power supply 24 VDC (18 - 32 VDC)
Power consumption 18 W 23 W 32 W
Protection (front/rear) IP66/IP20 IP66/IP20 IP66/IP66
(NEMA 4X/ 12 and UL Type 4X/ 12)
Operating temperature -30 °C to +70 °C
Relative operating humidity 5-95 % non-condensing
Storage temperature -40 to +80 °C
Vibration/shock 4 G / 40 G
>>
