Sem Factory Sem822 D Bulldozer 220HP Crawler Bulldozer with Bottom Price Easy to Operate Crawler Bulldozer
The electronically controlled hydrostatic drive system and multi functional joystick provide high levels of performance and maneuverability.The cabin is ergonomically designed for increased operator comfort and visibility. The advanced monitoring system tracks machine operating conditions and keeps the operator informed of all vital machines functions.The proven hydrostat design along with world class pump and motors provide a highly reliable tractor. The undercarriage components are designed for longer life versus the leading competitor.The SEM tractors are designed for easy access to reduce overall maintenance time.The machines electronic control module allows for quick troubleshooting.
| Model |
|
| Model | SEM816D | SEM816D LGP | SEM816D DS | SEM816D CH | SEM816D FR |
| Main Configuration |
|
| Operating Weight | 17,560kg | 20,150kg | 20,420kg | 17,820kg | 18,580kg |
| Ground Pressure | 66.8kPa | 31.1kPa | 34.8kPa | 61.8kPa | 66.9kPa |
| Ground Clearance | 410mm | 410mm | 410mm | 410mm | 410mm |
| Max. Slope | 30 | 30 | / | 30 | 30 |
| Engine |
|
| Engine Model | WD10G178E25 | WD10G178E25 | WD10G178E25 | WD10G178E25 | WD10G178E25 |
| Rated Power | 131kW | 131kW | 131kW | 131kW | 131kW |
| Working Tool |
|
| Blade Type | SU / S | LGP | LGP | U | SU Forestry / S Forestry |
| Blade Capacity | 4.3m / 3.5m | 3.4m | 3.4m | 5.6m | 6m / 5.8m |
| Blade Width | 3,180mm / 3,590mm | 4,410mm | 4,410mm | 3,580mm | 3,180mm / 3,590mm |
| Blade Height | 1,240mm / 1,165mm | 1,000mm | 1,000mm | 1,400mm | 1,625mm / 1,625mm |
| Max. Blade Digging Depth | 430mm / 430mm | 470mm | 470mm | 430mm | 430mm / 430mm |
| Max.Blade Lift Ground Clearance | 1,041mm / 1,041mm | 1,055mm | 1,055mm | 1,041mm | 1,041mm / 1,041mm |
| Max.Output Rimpull | 280kN | 280kN | 280kN | 280kN | 280kN |
| Max. Digging Depth of Ripper | 584mm | / | / | 584mm | 584mm |
| Max. Clearance Under Tip | 615mm | / | / | 615mm | 615mm |
| Powertrain |
|
| Type | dual-path, closed loop electronically controlled hydrostatic drive system | dual-path, closed loop electronically controlled hydrostatic drive system | dual-path, closed loop electronically controlled hydrostatic drive system | dual-path, closed loop electronically controlled hydrostatic drive system | dual-path, closed loop electronically controlled hydrostatic drive system |
| Travel Speed-F/R | infinitely variable speeds 0-10 km/h | nfinitely variable speeds 0-10 km/h | infinitely variable speeds 0-10 km/h | infinitely variable speeds 0-10 km/h | infinitely variable speeds 0-10 km/h |
| Steering & Brake | hydrostatic steering; wet, multi-disc brake | hydrostatic steering; wet, multi-disc brake | hydrostatic steering; wet, multi-disc brake | hydrostatic steering; wet, multi-disc brake | hydrostatic steering; wet, multi-disc brake |
| Minimum Streeing Radius | 3,610mm | 3,740mm | 3,740mm | 3,610mm | 3,610mm |
| Undercarriage |
|
| Track Shoe Width-Single | 510mm | / | 950mm | 560mm | 560mm |
| Track Shoe Width-APEX | / | 1,050mm | 950mm | / | / |
| Track Shoe Quantity | 37 | 42 | 42 | 37 | 37 |
| Track Length On Ground | 2,430mm | 2,925mm | 2,925mm | 2,430mm | 2,430mm |
| Track Gauge | 1,880mm | 2,300mm | 2,300mm | 1,880mm | 1,880mm |
| Track Roller Quantity | 6 | 7 | 7 | 6 | 6 |
| Carrier Roller Quantity | 2 | 2 | 2 | 2 | 2 |
| Hydraulic System |
|
| Type | center close, pilot control | center close, pilot control | center close, pilot control | center close, pilot control | center close, pilot control |
| Implement Hydraulic System Pressure | 19MPa | 19MPa | 19MPa | 19MPa | 19MPa |
| Service Refil Capacities |
|
| Fuel Tank | 320L | 320L | 320L | 320L | 320L |
| Cooling System | 45L | 45L | 45L | 45L | 45L |
| Hydraulic Tank | 140L | 140L | 140L | 140L | 140L |
| Pivot Shaft Case(each side) | 1.2L | 1.2L | 1.2L | 1.2L | 1.2L |
| Engine Crankcase | 24L | 24L | 24L | 24L | 24L |
| Final Drive(each side) | 30L | 40L | 40L | 30L | 30L |
