Floating Lacquer Sander Machine for Panel Components Processing

Product Description

Floating lacquer sanding machine is also called floating lacquer sander, or lacquer sanding machine or lacquer sander. It is used to connect with UV coating line for panel or furniture components processing.
Here are features:
1. Equipped with ultra-thick material detection system, which can effectively protect the sand roller. 2.The conveyor belt is equipped with dust cleaner on both sides, which can effectively ensure surface cleaning.
3. Air jet blower can prolong the abrasive belt life span, which can be extended by 20-30%
4. The lifting is adjusted by imported ball screw. Ball screw accuracy 0.008mm. Positioning accuracy 0.03mm
Reciprocating accuracy 0.005mm
5. SIEMENS brand contactor and relay are equipped inside machine.

Model	SFR-R1300V	SFR-R1000V	SFR-R700V
Max working width	1300mm	1000mm	700mm
Mini working length	300mm	300mm	300mm
Working thickness	3-100mm	3-100mm	3-100mm
Total motor power	26.15kw	25.35kw	17.65kw
Sanding belt size	1395x2100mm	1100x2100mm	850x2100mm
Air consumption	12m3/h	10m3/h	7m3/h
Overall size	2050x2130x2310mm	1750x2130x2310mm	1505x2130x2310mm
Total weight	3400kg	2800kg	2500kg

Sander 1 -Sander 2--Brush 1--Brush 2

Model	SFR-G1300V	SFR-G1000V	SFR-G700V
Max working width	1300mm	1000mm	700mm
Mini working length	300mm	300mm	300mm
Working thickness	3-100mm	3-100mm	3-100mm
Feeding speed	5-30m/min	5-30m/min	5-30m/min
Total power	20.1kw	19.3kw	13.6kw
Sanding belt side	1395x2100mm	1100x2100mm	850x2100mm
Air consumption	10m3/h	10m3/h	6m3/h
Overall size	2050x2130x2310mm	1750x2130x2310mm	1505x2130x2310mm
Total weight	3000kg	2800kg	2250kg

---
