Automatic Friction Waste Crusher and Washing Line Recyclable Plastic Machine

US$5,000.00-60,000.00 1 Piece (MOQ)

Basic Info.

Model NO.
TZ-500
Material Processed
Plastic Bottle
Plastic Type
PET
Screw
Multi-Screw
Automation
Automation
Computerized
Computerized
Certification
CE
Voltage
380V 50Hz 3phase
Capacity
0.5-3ton/Hour
Color
Customize
Final Product
Pet Flakes
Transport Package
by Sea
Specification
500kg/hour
Trademark
Taizy
Origin
China
Production Capacity
500kg/Hour

Packaging & Delivery

Package Size
2500.00cm * 380.00cm * 300.00cm
Package Gross Weight
30000.000kg

Product Description

Product Description
Product Description
Product description:
The raw material for our PET recycling machine is PET bottles, also called them cold water bottles.
The main function of PET recycling machine is to crush and clean the PET bottles.
In the process of crushing and cleaning, the raw materials of the bottle cap and the bottle body are different,
so the caps will be separated in the process, leaving only the bottle body. And the final product obtained
is clean PET flakes.
Production Process: 1. Climbing Conveyor:Convey the bottle to label removing machine. 2. Label Removing Machine: Remove the label from the bottle. 3. Sorting Conveyor:Transfer the no label bottle to another climbing conveyor,At the same time ,select again not fully removing label bottles and different colors bottles. 4. Climbing Conveyor:Convey the bottle to bottles crushing machine. 5. PET Bottle Crusher Machine:Crush the bottles into small chips. 6. Screw Conveyor:Convey the plastic chips into PET ,PP washing and separating machine. 7. PET, PP,PE washing and separating machine:washing and Separate PET chips and PE bottle cap. 8. Screw Conveyor:Convey washed PET chips into high temperature washing barrel. 9. High Temperature Washing Barrel:Wash PET chips with hot water and cleaning agent. 10. Screw Conveyor:Convey washed PET chips into rubbing washing machine. 11. Rubbing Washing Machine:With water recycling , clean the PET bottle enough ,remove cleaning agent and other impurity. 12. PET,PP,PP washing and separating machine:Separate PET chips and PE ,PP bottle cap completely . 13. PET Chips Dewatering Machine:Dewatering for PET chips
Capacity: PET recycling machine smalleast capacity is 500kg/hour. We also have 1000kg/hour,1500kg/hour,2000kg/hour and so on. We can customize according to your demands.
Application: 1.PET flakes can make packing belt. 2.PET flakes can add some other material to do something,such as add some lime to make tiles. 3.PET flakes can make new plastic products,these products can used for industry.
FAQ
Q1: Are you manufacturer or trade company?
A1:We are a professional manufacturer for producing machinery over 10 years.

Q2: How is the quality of your product?
A2: Our products are manufactured according to national and international standard, and we have a test on every machine before delivery.

Q3: How about the price?
A3: We are a professional manufacturer and be able to provide you with the lowest price than market one. We will give you the best quotation.

Q4:What if the machine is damaged?
A4:One year warranty and all-round after-sales service. After this deadline, we shall charge at low cost to keep after-sales service.
