China Supplier Servo System Automatic Plastic Sport Cap Closure Making Injection Molding Machine for Pet Bottles

Negotiable 1 Set (MOQ)

Basic Info.

Model NO.
SZ-3800A
Type
Preform Injection
Structure
Horizontal
Plastic Type
Thermoplastic
Plasticizing Way
Screw Type
Clamping Way
Hydraulic
Automation
Automatic
Computerized
Computerized
Certification
CE, ISO9001:2008
Plastic Processed
PP, PC, ABS, Pet, PVC, FRPP/PVC, PPR, HDPE, Mlldpe
Distance Between Tie Bars(mm)
680*680mm
Plasticizing Capacity(G/S)
60.5
Mold Height(mm)
250-710 mm
Ejector Number
13
Ejector Stroke(mm)
170 mm
Ejector Force(Kn)
90.7 Kn
Theoretical Shot Volume(Cm³)
1231cm
Injection Rate (G/S)
3575g/S
Injection Weight (G)
1120 G
Screw Speed (Rpm)
1-150
Screw Diameter (mm)
70 mm
Screw L/D Ratio
21
Weight (Kg)
15000
Transport Package
Wooden Box
Specification
3800KN
Trademark
ShenZhou
Origin
Jiangsu, China
HS Code
8477101090
Production Capacity
50 Set/Sets Per Month

Product Description



Standard Features of SZ-Series Injection Molding Machine SZ-3800A Parameter of Plastic Injection Molding Machine
ITEM UNIT SZ-3800A
INJECTION UNIT
SCREW DIAMETER mm 65 70 75
SCREW LID RATIO L/D 22.6 21 19.6
THEORETICAL SHOT VOLUME CM3 1061 1231 1413
SHOT WEIGHT(PS) g 966 1120 1286
INJECTION PRESSURE Mpa 203 175 152
THEORETICAL INJECTION RATE(PS) g/s 308 357 410
PLASTICISING CAPACITY g/s 50.6 60.5 71.5
SCREW TORQUE N.m 2860
MAX.SCREW ROTATE SPEED r/min 150
INJECTION STROKE mm 320
CLAMPING UNIT
MAX.CLAMPING FORCE K KN 3800
MAX.OPENING STROKE mm 680
SPACE BETWEEN TIE BARS mm 680×680
MOULD HEIGHT mm 250-710
MAX.DAYLIGHT mm 1390
EJECTOR FORCE KN 90.7
EJECTOR STROKE mm 170
EJECTOR QUANTITY 13
OTHER
PUMP MOTOR POWER KW 37
PUMP PRESSURE Mpa 16
HEATING POWER KW 25
HEATING ZONE 5
SIZE m 6.8×2.0×2.3
NET WEIGHT t 15
OIL TANK CAPACITY L 820
INTERNATIONAL DESIGNATION 3800-2150

Company Profile

Packaging & Shipping

Certifications

FAQ
1Q.Do you have an entity factory?
A1 Yes,We are a factory integrating industry and trade and have a whole set of production process.
Q2.How long is our delivery period?
A2 Actually, the delivery time of the machines is depended on the machine options. Normally, the delivery time of standard machine could be within 1-2 month.
Q3.What is the price of your injection molding machine?
A3 Our cost-effective performance is very high, the original parts of the machine are imported, wear-resistant, heat-resistant, high ductility.
Q4.How ahout your after-sales service?
A4 Our machines are guaranteed for life, if conditions permit, we will send engineers to overhaul.
