5ton Disk /Disc Hydraulic Explosion-Proof Qrh Quick Release Towing Hook

Product Description

50KN Quick Release Mooring and Towing Hook/Marine Towing Equipment device Harbor Triple Quick Release Mooring Towing Hook
Quick release mooring hooks is widely used due to its safety, reliability, feature of laborsaving and shortcut, etc, composed by stranded cable structure and release mooring structure.
Quick release mooring hooks systems composed by stranded cable structure and release mooring structure, the main functions below: Reelling the mooring rope automatically. The stranded cable mechine pulls the rope up to the bank automatically. The heavy work used to need two or three people could be finished easily by one people. Tying up safety and reliability. Under the situation of tying up working, the mechine is in the self-locking state, external force could not pull out the rope from cable hook, safety and reliability of anchoring. Casting loose quickly. During casting loose, operators turn the control handle to open the locked structure and the anchoring rope will release from hook and cast loose quickly. If emergency such as fire happens on the port or ship, the operator could use the ship leave the parking quickly, so as to guarantee the port or ship safety, avoiding the further extending of loss. Our company has years' experience on designing and Manufactuer ing of port operating devices, pursuing professional Manufactuer e of quick release mooring hooks systems, and absorbing the advanced technique of abroad, together with the reasonable structure and using the advanced processing technic. Strict management makes the products have reliable quality and safe use. Reccently, we produce single hook, double hook, triple hook, quadruple-hook, etc. among which the double hook and triple hook are the most widely-ranging used.
Our Quick Release Mooring Hook has the advantages of reasonable structure, reliable quality and safe use.We provide four types of quick release mooring hooks: single hook, double hook, triple hook, quadruple-hook; the double hook and triple hook are the most widely-ranging used.
Popular model: 40,60,75,100,125 and 150 tons.
Standard Coating
One Layer Epoxy Zinc,and One Layer Epoxy (Black color), Shot blasting to SA2.5.
Material:Including Q235-A ,Q345B etc
Certificate: ABS,LR,CCS,BV,DNV, etc.
Specification

SWL(Kn)	Weight(kg)	A	B	BB	C	CC	D	E	EE	F	G	H	K	L	M	N	R	T	Z	X
400	928	578	650	1120	100	470	70	235	300	35	370	1228	96	300	235	235	90	300	40	7*M647
600	1670	778	750	1185	115	445	78	275	330	45	407	1528	130	325	255	230	100	320	56	7*M72
750	2032	823	800	1300	150	505	86	290	355	45	417	1623	130	350	280	265	100	340	50	7*M80
1000	2807	859	850	1365	125	520	96	300	395	50	447	1709	150	376	295	265	125	362	60	7*M90
1250	3199	930	850	1365	125	520	96	300	395	55	479	1780	150	376	295	265	125	362	60	7*M90
1500	4698	1118	925	1570	170	605	86	325	435	55	499	2043	150	426	325	280	135	415	60	9*M80

We offers kinds of marine towing hook for your option, please take the bellow as reference:
* manual release spring marine towing hook
* manual release marine harbour towing hook
* manual release disc marine towing hook
* pneumatic spring marine towing hook
* pneumatic disc marine towing hook
* pneumatic marine harbour towing hook
* single quick release mooring hook
* double quick release mooring hook
* triple quick release mooring hook
* quadruple quick release mooring hook
* Marine Quick Release Disc Type Towing Hook
Quality Assurance and Service 1. Have a complete rigorous management, production and inspection processes to control the quality and avoid detail mistake 2. Design and produce ability 3. Rigorous inspection including incoming inspection, flaw detection etc., and double check is a must. 4. Advanced factory facility ensure 5. Response to any inquiry within 24 HRS with design or efficient solution from our engineer or tech supporter. 6. Provide professional customization service according to client's requirements 7. on time delivery, as we have rigorous production schedule and profession follow-up process 8. Moderate price and professional service PLC Control:
Drawing:
If you have any question or inquiry, please feel free to contact us for more details.

---
