US$2,000.00-3,000.00
|
1 set
(MOQ)
|
Basic Info.
Applicable Material
Metal and Part of Non-Metal
Cooling System
Air Cooling
Technical Class
Continuous Wave Laser
Laser Wavelength
Fiber Laser
Laser Classification
Solid Laser
Type
Optical Fiber Laser Marking Machine
Marking Method
Scanning Marking
Maximum Output Laser Power
100W Mopa Fiber Laser, Jpt
Wave Length of Laser
1064nm
Marking Scope
175*175/300*300mm
Laser Sources
Mopa Fiber Module
Field Lens
High Speed Scanning Lens
The Minimum Focus Facula Diameter
20um
Control System
Dlc Controller with Dongle
Marking Speed
Within 7000mm/S
Rotary Axis
Diameter 80mm, Chuck
Protection Case
Simple Type, 3 Sides
Focusing
Automatic, with Lifting Motor
Marking Depth
0.01-5mm( Depends on Different Materials)
Transport Package
Plywood Case
Specification
1320*970*1100mm, 167kgs,
Production Capacity
300set Per Month
Product Description
100W 2.5D Fiber Laser Marking Machine with Rotary Axis
Features
1. Adopting fiber laser to output laser, high electro-optic conversation rate, compact size, good quality velocity of light. The life time of JPT 100W MOPA fiber laser is more than 100,000 hours, if each year working 365 days, each day working 24 hours, then the life time is more than 10 years, are the real maintenance free, saving the later period maintenance cost.
2. With Famous SINO-GALVO 2206 serious galvanometer & High quality quartz stone material scanning lens, machine has good facula mode, more thin single line, suitable for hyperfine processing, high system integration, less malfunction, are the real suitable for industrial processing area.
3. DLC EzCad controller(software EZCAD3), supports 2.5D & rotary axis marking, can do 2D deep engraving, 3D intaglip relief engrave, supports STL DXF 3D file mark, support different front mark: TrueType, JSF, DMF, Bar code,DataMatrix QR code, etc. it compatible with other software like Photoshop, AUTOCAD, Coreldraw,users can use these softwares to make design then import the file to EZCAD to mark.
4. Vertical lift tith auto lifting motor to control the up down of scan head, so it can use to do 2.5D mark.
5. With rotary axis for cylinder marking
6. WIth simple protection case, for safe marking
7. No consumable, low power consumption, whole air cooling, no need water cooling, total machine power less than 1000W.
8. Not influenced by severe environment and bag weather, can continue working with accumulator when power failure.
9. One piece design of control cabinet and marking table, small cover area.
10. High perpendicularity of lifting device and marking table, suitable for small workpiece fine marking.
11. Marked graph and characters is permanent , will not regression due to friction.
Technical Parameters
Laser type
| Fiber laser
|
Maximum output laser power
| 100W JPT, China
|
Wave length of laser
| 1064nm
|
Marking scope
| 300*300mm/175*175mm
|
Laser sources
| Fiber module
|
Galvanometer
| SG2206, SINO-GALVO
|
Scanning lens
| Quartz stone material, CSDQ, China
|
The minimum focus facula diameter
| 20μm
|
Minimal character
| 0.01mm
|
Positioning
| Double red dot
|
Vertical shaft lifting height
| 700mm, with lifting motor
|
Control system
| Original EzCad 3 controller, supports 2.5D marking and rotary axis
|
Marking depth
| 0.01-5mm( depends on different materials)
|
Marking line width
| 0.01-0.1mm
|
Marking speed
| ≤7000mm/s
|
Laser repetition frequency
| 20kHz~80kHz
|
Cooling method
| Air Cooling
|
Power supply
| AC 220V, 50/60Hz, single phase
|
Support format
| PLT, BMP, DXF, JPG, TIF, AI etc
|
Process Material
| All kinds of metal and part of non-metal materials( opaque acrylic/plastic)
|
Certificate
| CE/FDA
|
Applications
2.5D fiber laser marking machine with EZCAD3 software, which have all the function of EZCAD2, can mark on flat surface of all metal material and part nonmetal material. It mainly use for mark on tools, metal parts, jewelry, firearms and industry polymers. Many users buy it as animal ear tag laser marking machine, jewelry laser marking machine, led bulb laser marking machine, etc. 50W or above power fiber laser marking machine can have some cutting ability by mark many times, it suit for do some cut work of thin metal sheet like silver, aluminum, brass, gold 1mm thickness.
2.5D Fiber laser marking machine with EZCAD3 software can do 3D engrave on metal like relief engrave, Intaglio engrave. It support import 3D file in STL, DXF format. This EZCAD3 2.5d fiber laser marking machine with electric up down scan head, can do quickly and permanently mark of text, picture, serial numbers, bar codes, QR code, for cylinder object, like ring, bracelet, bangles, stainless steel bottle, mugs, yeti cups. User can choose different rotary device according the size of objects he mark.
Working materials: can mark all metals and some nonmetals.
Metals: Gold,Silver,Stainless Steel,Copper,Aluminum, Brass,etc Alloy and metal oxides: Anodized Aluminum
Some non-metallic materials: silicon wafer, ceramics, plastic, rubber, epoxy resin, PVC, PC, ABS, Coating film etc.
The 50W 100w model can do some cutting work of thin metal like 0.5mm silver, 0.8mm silver or gold.
Accessories & packing
For more information, just feel free to contact us!
