| Model | ZZ1257S4641W |
| Engine | Engine model: WD615.47, Euro II emission standard, 4 stroke injection diesel engine, 6 cylinder in-line with water cooling, turbo-charging & inter cooling, mechanical high pressure oil pump system Maximum output: 371PS (273kW) at 2000 rpm Maximum torque: 1560Nm at 1200-1500rpm Bore: 126mm Stroke: 130mm Displacement: 9.726L Compression ratio: 17.5:1 Specific fuel consumption: ≤197g/kWh Engine oil filling quantity: 19L Air compressors: WABCO Twin cylinders air compressors |
| Clutch | SINOTRUK's 430C diaphragm spring clutch, hydraulically operating with air assistance |
| Transmission | Transmission, model HW19710, 10 forward and 2 reverse Ratio: 4.42 4.8 5.73 |
| Front Axle | New HF9 series, with drum brake system Steering with double T-cross section beam |
| Rear Axle | HC16 pressed axle housing, single reduction and differential locks between axles; with drum brake system. |
| Chassis | Frame: High-strength U-profile frame, all cold riveted cross members and reinforced subframe Front suspension: semi-elliptic leaf springs with hydraulic telescopic double-action shock absorbers and stabilizer Rear suspension: semi-elliptic leaf springs and bogie springs Spare wheel carrier: with one spare wheel |
| Steering | ZF8118, hydraulic steering with power assistance Ratio: 22.2-26.2:1 |
| Brakes | Front and rear drum brake, four-circuit protection valve Service brake: dual circuit compressed air brake Parking Brake: spring energy, compressed air operating on rear wheels Auxiliary brake: engine exhaust brake |
| Wheels&Tyres | Rims: 8.5-20,10 hole-steel Types: 12.00R20 Option:12R22.4,12.00-24,12.00-20,13R22.5, 315/80R22.5, 295/80R22.5, 11.00R20 |
| Driver'sCab | Long cab, all steel forward control, 55°hydraulic tilting to the front, 2-arm windscreen wiper system with 3 speeds, VDO electrical control system, laminate windscreen, with casted-in radio aerial, adjustable driver's seat and rigid adjustable co-driver's seat, heating & ventilation system, with stereo radio/cassette recorder, sun visor, safety belt, air conditioner |
| Electrics | Operating voltage:24V, negative grounded Starter: 24V, 7.5KW Alternator: 3-phrase, 28V, 1540W Batteries: 2×12V, 165Ah Cigar-lighter, horn, headlamp, fog light, brake lights, indicators and reverse lamp |
| Dimensions inmm | Wheel base (mm): 4600+1350 Front wheel track (mm): 2022/2041 Rear wheel track (mm):1830/1830 Overhang(front/rear) (mm):1500/2900 Approach angle(°):16 Departure angle(°):12 Overall Dimension (mm): 10350x2496x3048 |
| Weight in kg | Permissible loading capacity (kg):13540 Dead weight (kg):11330 Gross vehicle weight (kg):25000 Front axle loading capacity (kg):9000 Rear axle loading capacity (kg):2*16000 |
| Performance | Maximum driving speed(km/h):102(reference data) Maximum gradeability (%):62 Minimum ground clearance(mm):314 Minimum turning radius (m):10.8 Fuel consumption(L/100km):36(reference data) |
