High Quality Maize Rice Tractor Combine Harvester for Wheat

Product Description

High Quality Maize Rice Tractor Combine Harvester For Wheat
4 wheel reaper binder machine for rice reaper binder Application:

Reaper binder ,is the new product with the advanced technology and own property right,which is the unique type in India ,it is with transformation differential device ,slewing flexible .The machine is mainly used to harvest and Bind low stem crops such as wheat,Rice,Barley,Oats etc.

Advantages:
1. Small volume
2. Compact structure
3. Performance well
4. Harvest completely
5. Cast put

Feature
1. Advanced technology
2. Git wet and muddy land
3. Best engine
4. Optimum lodging device

Technical Parameter:

Model	QD-4K-150
Overall dimensions (L*W*H)	3550*1950*1330mm(without overhead guard)
Net weight	640kg
Reaping width	1400mm
Engine type	Single-cylinder, vertical, 4-stroke, air-cooled, direct injection
Displacement	0.499L
Output shaft rated speed(rpm)	1800pm
Calibration power	7.7/10.5 kw/ps
Start mode	electric starter
Lubricating oil capacity	1.65L
Gears/speed km/h	1st:2.9;2nd:5.3; 3rd:8.5;reverse:2.1;
Use fuel / tank capacity	diesel (0#)/6L
Clutch type	Main clutch -dry dual-plate clutch, harvesting unit clutch-jaw clutch
steering system	steering wheel control, differential steering system
Minimum turning radius	3M

---
