| Frame | High Reinforce Aluminum, anti-rust surface, GB6061-T6 ;100%"FENGLV "Aluminum Material Guaranteed; It can be used more than 30 years |
| Roof cover | 850g/m² and 660g/m² Double PVC-Coated Polyester, flame retardant, UV resistance, waterproof, comply to DIN 4102 B1, M2 ( European standard); 100% XingYiDa PVC Material Guaranteed - Perfect Fabric Cover Brand in China Recently. |
| Sidewall | Allowed Temperature Condition: -40°to +70°temperature Max Wind Speed Allowance: 120km/h Snow Load: 75kg/sqm |
| Connection | Hot-DIPPED Galvanized Steel Connections; 100% Zinc Shine Hot Dip Galvanizing Guaranteed |
| Product Name | Clear Span Aluminum Framework PVC Permanent Transparent Wedding Party Tent |
| Frame Material | Hard pressed Aluminum Alloy T6061/T6 |
| Roof Cover Material | 850g/sqm PVC coated polyester fabric |
| Siding Cover Material | 650g/sqm PVC coated polyester fabric |
| Side Wall | PVC Wall, Glass Wall, ABS Wall, Sandwich Wall |
| Span/Width | From 3m to 60m |
| Sidewall Height | 2.6m, 3m, 4m , 5m, 6m or Curtomized |
| Color | White, Transparent or Customized |
| Life Span | 8-10 Years |
| Max allowed wind Load | 80km/h |
| Max allowed snow Load | 75kg/sqm |
| Resistant Temperature | -30ºC to +70ºC |
| Features | Water Proof, UV Resistance, Flame Retardant(DIN4102,B1,M2) |
| Application | Wedding, Party, Event, Exhibition,etc |
| Accessories | Air Conditioner, Door, Heater, Flooring, Window, Curtain, Lighting etc. |
| Tent Size(m) | Side Height(m) | Frame Size(mm) | Footprint(sqm) | Accommodate Capacity (Events) |
| 5x12 | 2.6 | 82x47x2.5 | 60 | 40-60 people |
| 6x15 | 2.6 | 82x47x2.5 | 90 | 80-100 people |
| 10x15 | 3 | 82x47x2.5 | 150 | 100-150 People |
| 12x25 | 3 | 122x68x3 | 300 | 250-300 people |
| 15x25 | 4 | 166x88x3 | 375 | 300-350 People |
| 18x30 | 4 | 204x120x4 | 540 | 400-500 People |
| 20x35 | 4 | 204x120x4 | 700 | 500-650 People |
| 30x50 | 4 | 250x120x4 | 1500 | 1000-1300 People |
