Tomato Potato Classification Automatic Fruit Sorting Grader Machine

Product Description

Automatic Fruit Sorting Grader System for Potato Classification
Automatic Fruit Sorting Grader System for Potato Classification
Automatic Fruit Sorting Grader System for Potato Classification
1)Application of fruit sorter sorting grader machine:
It is suitable for sorting,cleaning,drying and processing oval fruits and vegetables like potato, citrus, navel orange, hawthorn, green kumquat, lychee, cherry tomato, cherries, kiwi, mango etc.
The sorting machine can be customized as customer's grades size.
2)Fruit sorter sorting grader machine structure and working principle
Cherry tomato grading machine consist of elevator and grading machine and outlet belt conveyors.
The elevator lift material automatically, and the roller rotate automatically to achieve uniform feeding, it can be equipped with water spraying device as requirement.
The grading machine is roller type. The double helix rotates which will drive the rollers on the grading bed moves forward in parallel, and increases the roller gap gradually to reach the corresponding size of the fruits and vegetables so that the fruits and vegetables fall down the outlet belt conveyors from the rollers gap which complete the fruit sorting finally.
The outlet belt conveyors are for people picking best fruit and worst fruit.
3)Fruit sorter sorting grader machine Technical Parameters:
-6GFJC-120-6T
-Capacity 3t/h
-Dimension: 7000*1400*900MM
-Power 1.1KW
-Voltage 220V/380V
4)More details of fruit sorter sorting grader machine
5)Packing&Shipping:
1,Generally packed in Plywood case.
2,Shipment within 10~20 working days after the advance/full payment.
3,We provide timely delivery. More importantly, if you don't know how to install machines, our professional technical staff will
assist you.
5)Our Service:
1, One year guarantee from exporting date.
2, If any easily damaged parts are found defective in quality for the first year, we will replace it for free.
3,We provide timely delivery. More importantly, if you dont know how to install machines, our professional technical staff will assist you.
NOTE:If you are interested in our fruit/vegetable sorter/sorting machine, just contact me for more information.

---
