OSB/ Lsb (Oriented Strand Board) Production Machine Line

Product Description

1. Raw material
OSB board is a kind of oriented structural board, which take small dimension wood, thinned wood, wooden core as raw material, be processed into sheets by special equipment (generally 40-100mm long, 5-20mm wide, 0.3-0.7mm thick), after removing oil, drying, sizing, directional paving, hot pressing.
Oriented strand board (OSB), also known as flakeboard, is a type of engineered lumber similar to particle board, formed by adding adhesives and then compressing layers of wood strands (flakes) in specific orientations. It was invented in California in 1963. OSB may have a rough and variegated surface with the individual strips of around 2.5 cm × 15 cm (1.0 by 5.9 inches), lying unevenly across each other and comes in a variety of types and thicknesses.

OSB is a material with favorable mechanical properties that make it particularly suitable for load-bearing applications in construction. It is now more popular than plywood, commanding 66% of the structural panel market. The most common uses are as sheathing in walls, flooring, and roof decking. For exterior wall applications, panels are available with a radiant-barrier layer pre-laminated to one side; this eases installation and increases energy performance of the building envelope. OSB also sees some use in furniture production.

Adjustments to the manufacturing process can impart differences in thickness, panel size, strength, and rigidity. OSB panels have no internal gaps or voids, and are water-resistant, although they do require additional membranes to achieve impermeability to water and are not recommended for exterior use. The finished product has properties similar to plywood, but is uniform and cheaper. When tested to failure, OSB has a greater load-bearing capacity than milled wood panels. It has replaced plywood in many environments, especially the North American structural panel market. Unfortunately, its use as sheathing has contributed to the leaky condo crisis, as it is less able to breathe and release moisture than plywood.
OSB board is a kind of oriented structural board, which take small dimension wood, thinned wood, wooden core as raw material, be processed into sheets by special equipment (generally 40-100mm long, 5-20mm wide, 0.3-0.7mm thick), after removing oil, drying, sizing, directional paving, hot pressing.
2. Land
Annual output of 120,000-150,000 cubic meter OSB production equipment occupy a land area of about 65000 square meters, including workshop, housing and raw material storage covers, and 8000 square meters production workshop and housing.
3. Workers
Workers: about 20-30days/shift, 3shifts/day, 300days/year
...... Equipment list (Part)

No.	Name	Model	Unit	Qty.	Power(kw)
0100	Wood Chips Making Section
0101	Peeling machine		Set	1
0102	Belt conveyer		Set	1
0103	Long bench wood planner		Set	2
0104	Belt conveyer for feeding		Set	2
0105	First layer chip making machine		Set	5
0106	Belt conveyer for discharging		Set	2
0107	Silo for surface layer		Set	1
0108	Silo for inner layer		Set	1
					450
0200	Drying & Screening Section
0201	Belt conveyer		Set	2
0202	Dryer		Set	2

FOR MORE INFORMATION,PLEASE CONTACT WITH US.

---
