Mt25ql128aba1ese-0sit nor flash memory IC agent

Product Details

Product Description

Product Description
Mt25q is a high-performance multi input / output serial flash memory device. It has high-speed SPI compatible bus interface, local execution (XIP) function, advanced write protection mechanism and extended address access function. Innovative, high-performance, dual and Quad I / O commands double or quadruple the transmission bandwidth of read and program operations.
The device provides an advanced security protection scheme. Each sector can be locked independently through volatile or nonvolatile locking function. The non-volatile locking configuration can also be locked and password protected.
features
• SPI compatible serial bus interface
• single and dual transmission rates (STR / DTR)
• clock frequency
– 133 MHz (value) for all protocols in str
– the frequency of all protocols in DTR is 90 MHz
• dual / quad I / O commands to increase throughput up to 90 MB / S
• protocols supported in STR and DTR
– extended I / O protocol
– dual I / O protocol
– four way I / O protocol
• local execution (XIP)
• program / erase pending operation
• volatile and nonvolatile configuration settings
• software reset
• additional reset pin for selected part number
• dedicated 64 byte OTP area outside main memory
– readable and user lockable
– use the program OTP command for permanent locking
• erase function
– batch erase
– sector erasure 64KB unified granularity
– sub sector erasure 4KB, 32KB granularity
• security and write protection
– volatile and nonvolatile locking and software
Write protection per 64KB sector
– non volatile configuration locking
– password protection
– hardware write protection: nonvolatile bits
(BP [3:0] and TB) define the size of the protected area
– program / erase protection during power up
– unexpected CRC changes detected
• electronic signature
– JEDEC standard 3-byte signature (ba18h)
– extended device ID: the other two bytes identify
Equipment factory options
• comply with jesd47h standard
– at least 100000 erase cycles per sector
– data retention period: 20 years (typical)

---
