Heavy-Duty 5t Lifting Jacks for Industrial Machine Applications

Product Description

5t Hydraulic Claw Jack Toe Hydraulic Jack

Main structure features:
this machine adopts manual operation do not need other power consumption, is mainly by manual lever to hydraulic drive the machine upper hooks for lifting movement, which has played a role, reasonable structure, easy to carry, is a practical machine.It widely used in the installation and maintenance of machinery and equipment, bridges, railway tracks, transport heavy loads handing; car and tractor repair. Feature of 5T/10T/20T/30T/50T Hydraulic Jack:
· For use where exceptionally low pick up height is required
· Extra wide base for maximum stability
· Electrically welded base and cylinder assures strength and eliminates leaks
· 200° handle socket for operation from any direction
· Load can be applied to toe or head
· Capacity rated at toe and increases if load applied to head
· Complete with overload protection
· Not affected by temperature extremes
· Tested to over 150% of rated capacities

Hydraulic toe jack	5 ton	10 ton	20 ton	30 ton	50 ton
Max. lifting capacity of the top	5 tons	10tons	20 tons	30tons	50tons
Max. lifting capacity of the hook	2.5tons	5tons	10tons	15tons	25tons
Max. lifting stroke	115mm	148mm	158mm	158mm	158mm
Mini.Hook Height	16mm	20mm	25mm	30mm	50mm
Size (mm)	210X140X232	260X200X283	295X220X322	305X255X350	340X285X350
Weight	11kgs	24kgs	36kgs	55kgs	75kgs

Thanks!

---
