Mach3 Operated Granite Carving Machine

Product Description

Experience unparalleled precision with our 1300x2500mm CNC Marble Engraving Machine, meticulously designed for stone and marble carvings.
1. Sturdy T-slot mesa and stable lathe bed ensure maximum stability during operations.
2. Advanced water cooling system extends cutter longevity, ensuring durability and efficiency.
3. Innovative breakpoints and power failure resume function guarantee uninterrupted carving.
4. Integrated dust oiling structure effectively ensures long-term mechanical reliability.
5. High-power water-cooled brushless motor enhances cutting capability and durability.
6. Premium imported and joint venture brand components ensure stable and reliable performance.
7. High compatibility with CNC software including Type3, ArtCAM, Castmate, Pore, Wentai, and various CAD/CAM systems.
8. Equipped with a sink and automatic water supply system, ensuring optimal cooling for both cutting tools and machining processes on stone and metal.
9. Industrial-grade body with heavy all-steel welded structure, tempering aging treatment, for unmatched durability and non-deformation.
10. Exclusive triaxial dust protection with waterproof technology safeguards the guide rail, gear, and rack from debris, extending the lifespan of components.
Applicable Industry
Perfect for the stone industry, stone processing, arts, advertising, decoration, and ceramics relief industries, among others.
Technical Parameters

Working size	1300×2500×200mm cnc stone machine
Spindle power	Water cooling 3000W
Spindle rotation	6000--24000rpm
Motor driver	Stepper motor driver(Chinese servo motor and Japan servo motor is optional)
Tool diameter	3.175, 4, 6, 12.7mm
Machine structure	Industry square tube structure
Transmission	High accuracy gear rack
XYZ rails	PMI square rails
Dust-proof system	XYZ high quality dust cover
Mechanical accuracy	0.03/300mm
Engraving speed	12000mm/min
Data transmission	PC connect directly
Support format	G code or HPGL
Working voltage	AC220V/50Hz or 380V/50Hz
Net weight	1500kg

Our stone CNC router machines are securely packed with standard inner plastic wrap, steel structure, and an outer plywood case. The inner package secures all small parts, while the firm plywood protects the machine during shipping.
The advantages of our plywood case packaging:
Firstly, the plywood case provides superior compressive strength and bearing quality, making it the preferred choice for heavy-duty packing.
Secondly, its large board area, robust structure, and simple operational process offer excellent leakproof and waterproof qualities.
Thirdly, our fumigation-free plywood case simplifies the import process, ensuring hassle-free procedures.

---
