Product Details
Product Description
Product Description
PVC Plastisol
l One-component, modified PVC material, neutral and environmentally friendly.
l Excellent thixotropy and extrudability, medium or high temperature curing.
l The surface is paintable, compatible with most industrial paints, and can be powder coated and painted after glue application.
l Excellent weather and ageing resistance, superior tensile and compression resilience.
l Excellent adhesion to metals such as aluminium, painted steel, PVC, ABS and polyester materials.
Product Details
QLD560 High Temperature Powder Coating Adhesive
It is used for sealing the seams of carriage welds, equipment parts, etc., and high temperature powder spraying and painting.
QLD564 Shiatsu Sealant
It is used where the body sheet metal has a large fit gap and it is difficult to seal the sealant outside the seam.
QLD561 Expansion Vibration Isolation Rubber
It is used for sealing areas such as the roof, front hatch, front and rear door crash bars, and rear back doors of cars.
QLD 565 Weld Sealant
It is used for sealing the welded seams of carriages in automobiles, trains and high-speed railways, and sealing the seams of mechanical equipment and so on.
QLD563Spot Welding Sealant
It is coated on the lap joints of welded steel plates and fills the gaps after spot welding to ensure sealing and prevent rusting.
QLD566 Anti-Stone Strike Primer
It is suitable for the coating protection of car chassis, train carriages and other equipment in the anti-rock impact area.
Product performance
Product Type
| QLD560
| QLD561
| QLD563
| QLD564
| QLD565
| QLD566
|
Rubber Appearance
| White plaster
| Blue-black paste
| Black paste
| White plaster
| White plaster
| Gray-black paste
|
Density (g/cm)
| 1.5±0.1
| 1.4±0.1
| 1.4±0.1
| 1.4±0.1
| 1.4±0.1
| 1.4±0.1
|
High temperature sag resistance (L1+L2,mm)
| 0
| ≤5
| ≤5
| ≤5
| ≤5
| ≤10
|
Non-volatiles (%)
| ≥98
| ≥98
| ≥98
| ≥98
| ≥95
| ≥98
|
Solidification conditions
| 200℃,15min
| 160-180℃，30min
| 140-160℃，30min
|
Shear strength (MPa)
| ≥1.2
| ≥0.3
| ≥0.6
| ≥1.0
| ≥1.2
| ≥1.2
|
tensile strength (MPa)
| ≥1.0
| /
| /
| /
| ≥1.2
| ≥1.2
|
Elongation at break (%)
| ≥100
| /
| /
| /
| ≥100
| ≥100
|
Shore hardness (A)
| ≥50
| 10-40
| 10-40
| ≥40
| ≥40
| ≥40
|
Expansion rate (%)
| 0
| 10-80
| ≤10
| 0
| 0
| 0
|
Stone chip resistance (1kg,10 times)
| /
| /
| /
| /
| /
| 0-1
|
Heat resistance/moisture resistance/salt spray resistance
| No cracks, no bubbles, no embrittlement, no reduced adhesion, no rust on the substrate
|
Environmental indicators
Project
| Total carbon volatilization
| Smell
| Atomization value
| Aldehydes
| Benzene series
|
Enforce the standard
| VDA277
| VDA270
| DIN75201
| VDA275
| VDA277
|
Standard value (≤)
| 50μgC/g
| 3.5
| 5mg
| 10μg/g
| 5μg/g
|
Packing specifications
Plastic cylinders
| 300ml/tube, 25 tubes/carton
|
Plastic cylinders
| 5 gallons(25kg)
|
Tin bucket
| 55 gallons(250kg)
|
Operational process
1. The surface of the seam should be free of oil stains, dust, impurities, etc.;
2. Apply the sealant evenly to the seams, and the thinnest part is greater than 1mm; When using a pneumatic gun, the air pressure is controlled at 0.2-0.4MPa;
3. The product is heated under curing conditions and can be trimmed using conventional methods after curing.
Precautions
1. void working on it in environments below 5℃
2. The pneumatic pressure is strictly forbidden to exceed 0.5MPa, and the gas will enter the rigid packaging tube when it is exceeded, and the problem of colloidal bubbles will appear
3. It must be stored in a low temperature and dry environment with a shelf life of 3 months.
>>
