Basic Info.
Automatic Grade
Semi-Automatic
Fabrication Capacity
2"-16"
Transport Package
Plywood
Packaging & Delivery
Package Size
92.00cm * 48.00cm * 87.00cm
Package Gross Weight
170.000kg
Product Description
Product Features
Features of Electric Hydraulic Roll Groover Machine
*RG-6X Electric Hydraulic Roll Grooving Machine, specially crafted for creating roll grooves on lPS steel pipes ranging from 2" to 16" (DN50~DN400) SCH10 to SCH40. Perfect for use in workshops or on-site, this machine is equipped with a motor, hydraulic feeding pump, foot switch, and pipe stand for a complete roll grooving experience.
* The compact large-sized groove machine boasts exceptional versatility and robust performance. Its wide working size range and heavy-duty adjustable bracket make it suitable for varying-sized pipes.
*Specially designed roller set prevents flare on the pipe ends, and eases the installation of the grooved couplings.
*Inbuilt high-performance gear-reducing motor contributes to a compact size and low noise.
*The unique split-type hydraulic system prevents oil leaks and extends service life. Groove depth lock nut ensures high-quality grooves and high efficiency.
Product Parameters
Model:
| RG-6X
|
Suitable materials:
| Carbon Steel,SS Pipe
|
Fabrication Capacity:
| 2"-16" Pipe SCH10/SCH40
|
Power supply:
| 220V/110V
|
Frequency:
| 50HZ /60HZ
|
Max wall thickness:
| 10mm
|
Motor power:
| 1100W
|
Output speed:
| 23RPM
|
Packing gross weight:
| 170kgs
|
Packing size:
| 92*48*87cm
|
Drive Unit
Item Number
| Description
| Net weight
|
912040*
| Groove roller for SCH10 Anti-flare (2"~3")
| 0.45kg
|
912039*
| Groove roller for SCH10 Anti-flare (3½"~6")
| 0.45kg
|
912038*
| Groove roller for SCH10 Anti-flare (8"~12")
| 0.45kg
|
912056*
| Groove roller for SCH10 Anti-flare(14"~16")
| 0.45kg
|
Standard
Item Number
| Description
| Net weight
|
911022
| Drive roller 2"~3" (Φ60~Φ89)
| 1.30kg
|
911021
| Drive roller 3 ½"~6" (Φ101~Φ168)
| 1.30kg
|
911020
| Drive roller 8"~12" (Φ219~Φ325)
| 1.40kg
|
911143
| Drive roller 14"~16" (Φ355~Φ426)
| 1.60kg
|
912010
| Groove roller 2"~3" (Φ60~Φ89)
| 0.45kg
|
912009
| Groove roller 3 ½"~6" (Φ101~Φ168)
| 0.45kg
|
912008
| Groove roller 8"~12" (Φ219~Φ325)
| 0.45kg
|
912052
| Groove roller 14"~16" (Φ355~Φ426)
| 0.45kg
|
998026
| Foot Switch
| 1.50kg
|
998103
| Pipe stand for 2"~16" (Φ60~Φ426)
| 33.0kg
|
998011
| Pipe Stabilizer
| 2.80kg
|
Detailed Images
Product Specification
Application
Product Packing
Company Profile
Certification
General Terms 1. PAYMENT
We accept a 30% TT deposit and a 70% balance payment against the photo before delivery or 100% TT in advance.
2. LEAD TIMEWELPING can finish in around 10-15 days for standard and light OEM items.
3. WARRANTY
18 Months from delivery we take full responsebilityfor for parts with quality problems and provide them for free requirements
4. CUSTOMIZED DESIGN
Our experienced technical team can develop different solutions according to customers. MOQ is required for special requirements.
5. ABOUT AGENCY BUSINESS Welcome customers with sincerity and influence to discuss cooperation matters with us.
>>
