Flexographic and Gravure Printing Ink Solvent Based Ink Liquid Ink for PE, PP, OPP, BOPP Film

Product Description

Product DescriptionBA-SERIES GRAVURE INK FOR BOPP LAMINATED FILM
BA-series gravure ink for BOPP laminated flm is an ester soluble ink made of chlorinated polypropylene as the main resin, applicable to gravure printing and lamination of light packaging material with BOPP as its printing substrate.SCOPE OF APPLICATION
1. Suitable for reverse printing on BOPP film with surface tension ≥38dyn.
2. Suitable for the process of dry lamination,PE-extrusion lamination and solvent-free lamination, while not suitable for PP-extrusion lamination proces.
3. Suitable for light packaging products, while not suitable for retort packaging.
APPLICATION CHARACTERISTICS
1. Ester solvent performs as the main solvent of BA-series ink, as well as the major dilution solvent in the printing process.
2. Excellent printability, suitable for all kinds of gravure printing from low speed to high speed.
3. The printing residual solvents are very low, in line with environmental protection, safety, non-toxic and hygienic requirements.
Product ParametersPRINTING VISCOSITY

Printing speed		Above 200m/min	100-200m/min	Below 100m/min
Printing Viscosity/ Zahn Cup #3	Colors	13±1s	14±1s	15±1s
	White	12.5±1s	13±1s	13.5±1s

DILUTION SOLVENT RATIO
1. The dilution solvent reference ratio for white ink

Type	Ethyl acetate	N-propyl acetate
Quick-drying	100	/
Normal-drying	50	50
Slow-drying	/	100

2.The dilution solvent reference ratio for color ink

Type	Ethyl acetate	N-propyl acetate	N-butyl acetate
Quick-drying	50	50	/
Normal-drying	/	100	/
Slow-drying	/	50	50

Company ProfileHuangshan Shining Ink Technology Co.,Ltd and Novel (Huangshan) Packaging Co., Ltd are all wholly-owned subsidiary of Huangshan Novel Co.,Ltd,they are only 12km apart.While Novel (Huangshan) Packaging Company produce flexible packaging products,Huangshan Shining Ink Technology company produce liquid inks and fine chemicals for flexible packaging materials.
Huangshan Shining Ink Technology Co.,Ltd. is equipped with innovative resources such as Anhui Plastic Ink Engineering Technology Research Center and Provincial Enterprise Technology Center, the company is a high-tech enterprise integrating research and development, production and sales, and is also titled as Provincial Technological Innovation Demonstration Enterprise and the key enterprise of National Torch Plan Huangshan Industrial Base for Flexible Packaging New Materials.
Founded in 1995, the company has more than 120 employees, including more than 20 professional technicians and after-sales. The company has successively undertaken the implementation of National Torch Plan Project, Technology Innovation Fund Project by the Ministry of Science and Technology, National High-tech Industrialization Demonstration Project, and won the second and third prizes of Anhui Science and Technology Award, Anhui Quality Management Award, Anhui Outstanding Private Technology Enterprise Award, and other honors such as Famous Trademark of Anhui Province, Enterprise of Observing Contract and Valuing Credit in Anhui Province, Integrity Enterprise in Anhui Province.Certificated by ISO 9001, ISO 14001, and Level 3 National Safety Production Standardization, the company has obtained 9 invention patents and 45 utility model patents, with multiple products identified as provincial high-tech products. Besides, XINCAIYUN brand acrylic alcohol-soluble plastic lamination ink has won the honorary title of Anhui Famous Brand Product, and the alcohol-ester benzene-free and ketone-free ink has been included in the list of substitutes for toxic and harmful raw materials (products) encouraged by the state.
Adhering to people-oriented, and promoting development with technological innovation, the company is dedicated to being an excellent supplier of liquid inks and their application technologies, and takes vigorously promoting the development and progress of China's liquid ink industry as its responsibility.
STANDARD COLOR INFORMATION:

Code	Color
BA1004	Primary Red
BA2002	Primary Yellow
BA2007	Orange
BA5001	Black
BA3001	Primary Blue
BA6051	Green
BA4002	White
BA8002	Varnish
