Ajmtg Vmc1060 3 Axis Vmc Cutting Machine

US$35,000.00

1-4 Set

US$17,000.00

5+ Set

Basic Info.

Model NO.

VMC1060

Application

Metal

Process Usage

Metal-Cutting CNC Machine Tools

Movement Method

Linear Control

Control Method

Closed-Loop Control

Numerical Control

CNC/MNC

Performance Classification

High-End CNC Machine Tools

Certification

CE, ISO 9001

Condition

New

Worktable Size

500X1000, 600X1200

Transport Package

Good Wooden Case

Specification

2800x2500x2700

Trademark

AJMTG

Origin

China

HS Code

8457101000

Production Capacity

1200 Sets Per Year

Product Description

Welcome to Nantong AJ Industry Limited! Explore our top factory with the AJMTG VMC1060 3 Axis VMC Cutting Machine. Send inquiries and visit us today!
Nantong AJ Industry Limited presents the AJMTG VMC1060 3 Axis VMC Cutting Machine, a high-speed, multi-axis CNC milling center for efficient metal cutting.
Nantong AJ Industry Limited presents the AJMTG VMC1060 3 Axis VMC Cutting Machine, a high-speed, precision CNC milling equipment for industrial use. Explore our professional CNC machining center for efficient metal cutting.

Machining range	X axis travel	800mm
	Y axis travel	500mm
	Z axis travel	500mm
	Spindle nose to worktable	150-650mm
	Spindle to column guide	550mm
Worktable	Worktable size	1000x500mm
	T slot	18X5X90mm
	Weight load	500kgs
Spindle specification	Spindle	8000rpm belt drive Japan make
	Spindle motor	7.5kw
	Spindle taper	BT40(Ø140)
Feed system	G00 fast feed	48/48/36m/min
	G01 cutting feed	1-10000mm/min
	Servo motor	223kw
Tool system	Capacity	24 tools arm type Taiwan make
Main parts		Make
Ball screw		Taiwan C3 grade diameter 40mm, pitch 12/16mm
Linear guide		Taiwan HIWIN or Germany 35mm pin roller type
Spindle		Taiwan diameter 140mm , 8000 rpm
Tool magazine		Taiwan BT40-24 tools arm type
Bearing for 3 axis		Germany or Japan Nachi, Screw Angle Support Bearing 30X62

Export Certificate for AJMTG VMC1060 3 Axis VMC Cutting Machine by Nantong AJ Industry Limited. High precision CNC milling equipment for sale.
