US$3,000.00-4,000.00
|
1 Piece
(MOQ)
|
Basic Info.
Model NO.
X6332C XN6330H X6330H XS6330H
Type
Knee Type Milling Machine
Milling Cutter Type
Vertical Milling Cutter
Milling Cutter Structure
Indexable Type
Controlling Mode
Artificial
Certification
CE, RoHS, ISO 9001
Vertical Travel(mm)
420mm
Transport Package
Plywood Case
Production Capacity
10 PCS/Month
Product Description
MILLING MACHINE FEATURES:
The machine is suitable for machinery, light industry, instrument, motor, electrical appliance and moulds, and widely used in machining of plane and arbitrary angle plane, and slotting, drilling, reaming, boring etc.
TURRET MILLING MACHINE FEATURE:
1.TAIWAN milling head
2.Rectangular and dovetail guideway can available
3.Worktable travel of X-axis up to 800mm
4.Saddle becomes bigger
SPECIFICATIONS
| SPECIFICATIONS | X6332C |
| Table size mm | 1250X320 |
| Table travel | 800X300X350MM |
| Number/Width/Distance of T-slot | 3/14/70 |
| Distance between spindle nose and table surface | 150-500MM |
| Distance between spindle axis and column surface | 150-550 MM |
| Spindle travel | 150MM |
| Spindle taper(V/H) | 7:24 ISO40 |
| Spindle speed range RPM | 63-5817(V)60-1350(H) |
| Spindle motor power | 3.7(V)2.2(H) KW |
| Overall dimension | 1720X1520X2225 MM |
| Machine weight | 1770/1900KGS |
SPECIFICATIONS:
| SPECIFICATION | UNIT | XN6330H | X6330H | XS6330H |
| Table size | mm | 300X1300 | 300X1370 | 300X1500 | 300X1370 | 300X1500 |
| Table longitudinal travel | mm | 845 | 1000 | 880 | 1000 |
| Table cross travel | mm | 385 | 380 |
| Table vertical travel | mm | 435 |
| Table longitudinal feed rate | mm/min | 0-3500
Servo motor | --- |
| Table cross feed rate | mm/min |
| Knee vertical feed speed | mm/min | 900 |
V
| Motor power | HP | 5HP | Standard:3HP/Optional:5HP |
| Spindle speed | rpm | Standard:16steps, 50HZ: 65-4500/60HZ:80-5440
Optional:variable speed: 65-3750 |
| Spindle taper | | ISO40 | Standard:R8/Optional:ISO40 |
| Quill travel | mm | 127 |
| Quill feed | mm/r | 0.04/0.08/0.15 |
| Head rotating | | R/L 90° | R/L 90°, B/F 45° |
| Distance from spindle nose to table surface | mm | 115-545 |
H
| Motor power | HP | 5HP |
| Spindle speed | rpm | 50HZ: 45/80/165/260/500/980
60HZ: 55/100/200/315/600/1180 |
| Spindle taper | | ISO40 |
| Distance from spindle to table | mm | -20-410 |
| Distance from spindle to arm | mm | 183 |
| Arm travel | mm | 480 |
| Arm rotating angle | | 360° |
| Net weight | kg | 1900 | 1950 | 1680 | 1730 |
| Package size | m | 1.8X1.5X2.2 | 1.8X1.8X2.2 | 1.8X1.6X2.2 | 1.8X1.8X2.2 |
>>
