| Product | Lifting Two-layer Glass Reactor | |||||
| Model | GRL-10 | GRL-20 | GRL-30 | GRL-50 | ||
| Effective reaction capacity(L) | 10 | 20 | 30 | 50 | ||
| Jacket capacity(L) | 3 | 6 | 10 | 16 | ||
| Jacket heat exchange area(m²) | 0.22 | 0.32 | 0.32 | 0.65 | ||
| Condenser heat exchange area(m²) | 0.2 | 0.3 | 0.3 | 0.3 | ||
| Glass parts material | High borosilicate glass 3.3 | |||||
| Kettle body tolerable temperature(℃) | -80～200 | |||||
| Kettle body resistance to temperature difference (℃) | 90 | |||||
| Operating pressure(MPa) | Vacuum or normal pressure | |||||
| Motor | Power(W) | 90 | 90 | 90 | 120 | |
| Regulation method | Electronic speed regulation | |||||
| Stirring speed(rpm) | 50～500 | |||||
| Six ports on the cover | Stirring port | |||||
| Sensor port | ||||||
| Condenser connecting port | ||||||
| Liquid charging port | ||||||
| Constant pressure funnel connecting port | ||||||
| Solid charging port | ||||||
| Inlet/outlet liquid circulation nozzle | DN15 | |||||
| Overall Power Supply(V/Hz) | 220/50 | |||||
| The height of the draining valve from ground ( mm ) | ≤590mm | ≤585mm | ≤585mm | ≤540mm | ||
| Temperature sensor material | Stainless steel covered with PTFE outside, double anti-corrosion | |||||
| Stirring | Rotary vane agitator, stainless steel axis covered with PTFE outside | |||||
| Dimension (mm) | 1100L×660W×1990H | 1100L×655W×2030H | 1100Lx665Wx2455 | 1100L×680W×2455H | ||
