2.2kw High Shear Mixer High Shear Emulsifying Mixer for Daily Chemical

US$495.00
10-29 Pieces
US$475.00
30-49 Pieces
US$485.00
50-99 Pieces
US$425.00
100-199 Pieces
US$395.00
200+ Pieces

Basic Info.

Model NO.
RH-2.2-304
Certification
CE, ISO
Mixing Capacity
500-1000L
Mixing Drum Shape
Drum
Speed Control
Variable Speed
Speed Range
60 R/min & Above
Stirring Type
Forced
Temperature Control
With Heating
Type
High Shear Homogenizer
Warranty
1 year
Working
Shear Mixer
Material
SS304 / SS316
Shaft Length
500
Stator Type
Disintegrated Stator
Rotor Tyoe
Claw Rotor
Motor Power
220V 60Hz 3phase
Mixer Type
Homogenizer
Specification
3HP/2.2kw
Trademark
ranking
Origin
China
Production Capacity
5000PCS Per Month

Packaging & Delivery

Package Size
850.00cm * 26.00cm * 39.00cm
Package Gross Weight
45.000kg

Product Description

2.2kw 3HP high shear emulsifying mixer batch type emulsifier
(high shear emulsifying mixer 2.2kw 3HP)
batch high shear mixer can be permanently mounted to a mixing tank or suspended over the stainless steel vessel using a portable or permanent lifting mechanism. Compared with the continuous operating inline shear mixer, batch type mixer is an ideal mixer for cycle operating. 1.1kw~90KW ones batch type high shear emulsifying mixer avaliable
Cycle Operating / batch type High shear emulsifying mixer application
Food Industry: chili sauce, gingili, fruit tea, ice cream, butter, jam, soy, miso, red bean paste, peanut milk, protein milk, soymilk, dairy product, malted milk, essence, condiment and all kinds of food and beverage etc.
Chemistry Industry: oil paint, pigment, dye, dope, lube, diesel oil, oil catalyst, asphalt emulsion, modified asphalt, paraffin, adhesive, scour, plastic, , FRP, synthetic leather, colophony, leather and emulsion explosives.
Daily Chemical Industry: toothpaste, scour, cream, lipstick, facial, shampoo, shoeshine, cosmetic, shower concentrate, soap, coagulant and flavor.
Medical Industry: syrup, nutrient solution, Chinese medicines, pharmacy paste, biological agents, cod liver oil, pollen, placenta, bacterin, ointment, liquid, fungicides, injection, antibiotics, micro encapsulation and intravenous fluid.
Construction Industry: all kinds of dope including internal and external wall dope, antisepsis and waterproof dope, cold porcelain dope, colorful dope, ceramic glaze, nano dope and spraying.
Paper Making Industry: paper pulp, adhesive, rosin emulsion, paper additives and resin emulsion.
Pesticide Industry: antiseptic, herbicide, pesticide EC, fertilizer, biochemical pesticide and biological pesticide.
Other Industries: spin industry, coal flotation agent, rare earth, nano-material scattered depolymerization, reaction, extraction and war industry.
2.2KW 3HP high shear emulsifying mixer homogenizer wetted material
wetted material is a reference to the sub-compnment of the high shear homogenizer that is in contact with the process media (liquid / cream / oil-water mixture, water-powder mixture) include the stator, rotor, driving shaft and the support shaft. Ranking machinery offer both stainless steel 304 and SS316L as the wetted material for all our high shear emulsifying homogenizer.
3HP 2.2kw Cycle Operating Emulsifying Homogenizer Specification
Model motor power
kw
shaft length
mm
wet materal Processing Ability
Liter/min
Remark
RH-1.1-304 1.1 450 SUS304 10-40
RH-1.5-304 1.5 550 SUS304 20-70
RH-2.2-3.4 2.2 650 SUS304 50-100
RH-3-304 3 700 SUS304 100-200
(please contact our sales team to get specification for other models of our high shear mixer)
about the price
2.2kw 3HP high shear emulsifying mixer homogenizer wetted material
The price for all the cycle operating high shear emulsifying mixer / highs hear homogenizer in this site only for reference.
Prices are subject to market conditions and other factors such as exchange rate, raw material price etc.
Please cotact our online sales team to get the latest price for all the high shear mixer and similar product.
