US$520.00-610.00
|
1 Piece
(MOQ)
|
Basic Info.
Model NO.
BR-BLH-19200W Lithium Battery
Battery Size
453*433*177mm
Certification
CE/Rosh/MSDS/Un38.3/IEC/ISO9001/ISO14001
Nominal Capacity
4.8/9.6/14.4/19.2kwh
Cycle Life
More Than 6000 Times
Inverter Matched
Solax, Deye, Goodwe, Growatt, Victron, Sofar, Gmde
Standard Voltagee
51.2V /48V
Usage
Solar Energy System, Battery Back up, UPS Backup
Transport Package
Carton with Pallet
Specification
453*433*177mm
Origin
Jiangsu, China(Mainland)
Production Capacity
100000PCS/Month
Product Description
Specification
| Module Type | LFP 4.8kWh | LFP 9.6kWh |
| Total Energy* | 4.8kWh | 9.6kWh |
| Usable Energy(DC)* | 4.32kWh | 8.64kWh |
| Constant Current (Only Discharge) | 105A | 105A |
| Voltage | 44.8~57Vd.c |
| Nominal Voltage | 48Vd.c |
| Nominal Current | 100A |
| Max. Charge Voltage | 57V+_0.5V d.c |
| Weight | 54kg/108kg |
| Dimension(mm) | 525*153*855mm |
| Safety | CE UN38.3 |
| Max.recommended DOD | 90% |
| Operating Condition | Indoor or outdoor |
| Operating Charge | From 0~50ºC |
| Temperature Discharge | From -20~60ºC |
| Cooling Type | Natural Cooling |
| Case Material | Metal |
| IP rating | IP 65 |
| Max. Number of Parallel or Series | 16 |
| Cycle Life | >6000 |
| Communication | CAN |
| Protection Mode | Triple hardware protection |
| Battery Protection | Over-current/Over-voltage/Short circuit/ Under-voltage |
| Hazardous Material Classification | 9 |
The whole module is non-toxic, non-polluting and environmentally friendly;
Cathode material is made from LiFePO4 with safety performance andlongcycle life;
Battery management system(BMS)has protection functions includingover-dis-charge, over-charge, over-current and high/low temperature;
Small size and light weight, comfortable for installation and maintenance.
Packing & Shipping
Project of BR SOLAR Our Projects are applied all around the World We Choose A Quality Material, Quality Is Our Culture.So Our Solar Products Have Been Successfully Applied In More Than 110 Countries Including UN Projects and NGO Projects.
Certificates Of BR SOLAR
Payment Terms and Delivery
| Payment Terms | T/T | EXW | 30% In Advance, 70% Balance Paid Before Delivery |
| FOB |
| CFR/C&F | 30% In Advance, 70% Against Copy Of B/L |
| CIF |
| L/C | Total Amount Above USD100,000, We Accept L/C At Sight |
| West Union | Total Amount Less Than USD1,000 |
| PayPal |
| Delivery Time | 15-20 Working Days After Receiving Down Payment |
