CW6163 Heavy floor 3m horizontal manual lathe machine with CE

Product Description

Product Description
Features:
This heavy duty horizontal face lathe series include : CW6163B,CW6180B,CW6280B, CW6110B.This lathe is a special purpose heavy duty horizontal face lathe and it is suitable for turning the internal/external cylindrical surface, conical surface, end face and so on with large-diameter, medium length for all kinds of workpieces .

Main specification :

Specification	Unit	CW 6163B (without gap) CW6263B (with gap)
Swing over bed	mm	630
Swing over toolpost	mm	350
Swing over gap	mm	1300
Center distance	mm	1000mm 1500mm 3000mm 5000mm
Spidle bore size and spindle type	mm	φ120 D11
Spindle nose taper and center taper		φ140 MT5
Spindle speed kinds anf range	r/min	18 kinds 5.4-720
Longitudinal Feeding speed and range	mm/r	64 kinds 0.06-24.3
Range 1:1	mm/r	0.1-1.52
Range 16:1	mm/r	1.6--24.3
Micro feeding with change gears	mm/r	0.05-0.76
Ratio of cross feeding and longitudinal feeding	mm	1:2
Bed fast moving	mm/min	4000
Leadscrew pitch	mm	Metric 12 inch 1/2"
Metric thread range	mm	50kinds 1-240
Inch thread range	tpi	26 kinds 14-1t.p.i
Module thread range	mm	53 kinds 0.5-120
Pitch thread range	mm	24kinds 28-1 DP
Max. travel of Upper toolpost	mm	315
Max. travel of Lower toolpost	mm	200
Tailstock travel	mm	250
Tailstock taper		MT5
Main Motor power	KW	11
Fast moving motor power	KW	1.1
Coolant pump power	W	90
Bed width	mm	550
Bed hardness		600RC52
Max. Loading weight	kg	1500

Detailed Photos
Company Profile
FAQ
Q1: How is the warranty?
A1: Warranty time is 13 months after BL date.
Q2:Can we visit your factory before order?
A2:Sure.All new and old friends are welcomed to visit us at our factory. Besides, we can pick up you at the station or airport if needed. We will be very honored to help with tickets and accommodation booking.
Q3:Do you have a stock?
A3:Sorry, most of our machines don't have stock, we always produce according to order. However, if during fairs months, maybe have few samples back from fairs.
Q4:What's the MOQ?
A4:One set only.
Q5:How about your quality?
A5:We have approved the ISO9001:2008 Quality management system.ISO14001 Environmental management system, OHSAS18001 International occupational health and safety management system, and Social Accountability 8000(SA8000). Most products have been approved by the European and American safety standards, including CE, GS, EMS&UL,90% of our products are exported to more than 60 countries and regions around the world, especially to Europe and America market and always win high reputation. So you can rest assured of our quality products and our best services.
Q6:Do you have professional engineers?
A6:Yes.we have professional engineers and designers. We can provide OEM services.
Q7:Can you provide customized machines?
A7:Yes, we can design and manufacture according to your specific requirements.

---
