Polarizing Plate Beamsplitter/YAG Plate Beamsplitter/Multiple Laser Beamsplitter

Product Description

General Introduction: Raytek's high energy Nd: YAG laser 50/50 splitter is made of high purity fused silica substrate and superhard dielectric coating. After relevant testing and certification, the beam splitter can withstand high energy pulse with high damage threshold..
Products Name: High-Energy Nd:YAG Laser Beamsplitters
Alias: Laser Line Plate Beamsplitters,Laser Plate Beamsplitters, Laser Line Plate Beam splitters, Laser plate beamsplitters, Laser beam splitter plate, Nd:YAG Laser Beamsplitters, High-Energy Laser Beamsplitters, etc
Bandpass Filters Substrates:
UV Grade Fused Silica

Optional I:	UV Grade Fused Silica from CORNING, OHARA, SCHOTT, LEONI, AGC,HELLMA, NIKON,VITRON,ETC
Optional II:	Equivalent UV Grade Fused Silica Made in China, C-laser own brands

Main Applying:

Applying Fields I:	Parallel transmission of information and energy in laser communication, optical storage, optical interconnection, laser 3D imaging, laser processing and other fields.
Applying Fields II:	In laser communication, multi-channel parallel transmission of fan out and lidar multi-point parallel transmitting antenna is proposed; In laser processing, the two-dimensional multi-point laser drilling, laser marking, fast multi-point parallel 3D laser printing, as well as the multi-point array laser spot removing and laser skin rejuvenation in laser micro invasive medical and beauty treatment.
*****

Main Characters:
1).Designed for Nd:YAG laser fundamental and harmonics
2).Equal 50/50 (R/T) beam split for S or P polarization
3).Low wavefront distortion
4).Hard refractory coatings for high damage threshold
5).10-5 scratch-dig surface quality
6).AR coated back surface eliminates ghosting
7).Versatile Coating Options
8).UV Fused Silica Substrate
9).Slight Wedge Suppresses Unwanted Fringes
10).High Damage Threshold
11).Reflectance Outside the Design Wavelengths
Products Highlights:
1).Different grades materials for option.
2).High precision & high surface roughness;
3).Sizes can be customized as per the customers' request
4).Quick lead time and delivery time.
5).Matching super optics custom and processing capacity, including Moulding, CNC machining, Polishing, Particle beam processing, Magnetic flux conversion processing, Grinding, Coating, Lightweighting, Custom Shaping, Counterbores, Drilling & Coring, Edge & Bevel Polishing,3D Contouring, Bevels & Chamfers, Steps & Slots, Laser Cutting & Marking, Metrology & Inspection, Precision Pitch Polishing, Double-Sided Polishing, Optical Assembly, Measuring, etc.
6).Excellent post-sale quality warranty, with "3R"-return, replace & refund policy
Main Optical Tech Specification:

Tech Data	Description
Type	Plate Beam splitters
Material	UV Grade Fused Silica
Coating Type	HBS.11P/HBS.11S/HBS.13P/HBS.13S HBS.27P/HBS.27S/HBS.33P/HBS.33S
Antireflection Coating	V-coat AR, R <0.5%
Surface Quality	10-5 scratch-dig
Surface Flatness	≤λ/10 at 632.8 nm over the clear aperture
Extinction Ratio	-
Wavefront Distortion	-
Angle of Incidence	45°±3°
Damage Threshold	0.25 MW/cm2 CW, 2.5 J/cm2 with 10 nsec pulses at 266 nm, typical
Orientation	-
Reflection	-
Reflected Beam Deviation	-
Transmission	-
Transmitted Beam Deviation	-
Clear Aperture	> central 85% of diameter
Polarization	-
Operating Temperature Range	-
Parallelism(Wedge)	30 ±15 arc min
Chamfers	0.25-0.76 mm face width
Chamfers Angle Tolerance	45° ±15°
Durability	MIL-C-675C, moderate abrasion million cycles

Popular Physical Size Specification:

Size	25.4mm/50.8mm or Design & custom manufacturing as per demand.
Size Tolerance	+0/-0.13 mm
Thickness	Design and custom as per demand
Thickness Tolerance	±0.38 mm
Wavelength Range	266nm/355nm/532nm/1064nm,or other

Main Cooperation Materials Manufacturers:
CORNING, OHARA, SCHOTT, LEONI, AGC,HELLMA, NIKON,VITRON,C-LASER,ETC
Main Export Countries & Areas:
Usa, Uk, Japan, Germany, Spain, France, Swiss, Korea, Russia, Pakistan, India, Portugal, Canada, New Zealand, Australia, Saudi Arab, Turkey, Finland, Poland ,etc.
Raytekoptics Extra value added services offered:
1). Optical workcraft & process solution design;
2). Rough processing raw materials;
3). Semi finishing raw materials;
4). Fabricate custom sizes and shapes;
5). Design and supply custom coatings;
6). Modify and resurface customer supplied materials;
7). Drill holes, notch glass and provide beveled substrates;
8). Precision polish optics with non-standard aspect ratios;
Payment Method: by T/T or Western Union.
Delivery time: 7-10 days.
Quality Warranty: Ruitaiphotoelectric(Raytekoptics) offers quality warranty for our optics products with "3R" policy. For any inferior-quality products, Ruitaiphotoelectric(Raytekoptics) is responsible for return, replacement and refund.

---
