| US$525.00-750.00 | 1 Ton (MOQ) |
| Name | Red Color 0.30*900*3000mm Color Coated Plated Corrugated Steel Roofing Sheet | ||
| Type of substrate | Hot dip galvanized, Galvalume, Electro galvanized,Zinc alloy, Cold rolled steel, Aluminum | ||
| Thickness | 0.125-2mm | ||
| Tolerance | Thickness: ± 0.01mm | ||
| Width | 600-1250mm ( Normal:1250, 1200,1000,914 mm) | ||
| Top Paint | 10-25 micron(Normal:10-12mic) | ||
| Back paint | 5-12 micron(Normal:5-7mic) | ||
| Coating | Zn coating | AZ coating | |
| 30-400gsm | 30-400gsm | ||
| Coil weight | 3-5 tons or as your requirement. | ||
| Coil ID | 508/610 mm | ||
| Grade | Galvanized | Galvalume | |
| SGCC/DX51D+Z, DX52D+Z, SGCD/DX53D+Z,SGCE/DX54D+Z, SGCH....... | DX51D+AZ, DX52D+AZ, DX53D+AZ, DX54D+AZ,SGLCC,SGLCD,SGLC4 40,SGLHC........ | ||
| Coating type | Top paint: PE, SMP, HDP, PVDF, PU | ||
| Functions: Decorative, Machinability, Weather resistance, Scrath resistance, Stain resistance, Chemical resistance, Adhesion resistance | |||
| Primer paint: Polyurethane, Epoxy, PE | |||
| Functions:Machinability, Corrosive resistance, Adhesion, Scrath resistance | |||
| Back paint: Epoxy, Modified polyester | |||
| Functions: Scrath resistance, Bending adhesion, Corrosive resistance | |||
| Type of coating process | Front: Doulbe coated & double drying | ||
| Back: Double coated & double drying, single coated & double drying | |||
| Double coated & double drying is used for corrugated sheet | |||
| Double coated & single drying is for sandwich panel | |||
| Packing | Standard export package .Plastic film in the first layer,second layer is Kraft paper. Third layer is galvanized sheet. | ||
| Application | Building industry ,structural use, roofing, commercial use ,household appliance, industry facilities, office buildings | ||
