Auto Grinder High Precision on Grinding Surface Turret Punch Press Tool Grinding Machine

Product Description

Product Description
The benefits of accurate regrinding include:
1.Burr-free, quality parts straight off the punch press
2.Longer tool life for reduced tooling costs
3.No scrapped or wasted sheets due to tooling malfunction
4.Reduced wear on your punch press
Product Parameters

Model	IS-160	WG-150
Voltage	AC 380V 50HZ	AC380V 50HZ
Power of Main Motor	2.2KW 2840RPM	0.55KW 60 RPM
Motor of Rotating Table	0.1KW 1440RPM	0.1KW 1440 RPM
Servo Motor	0.75KW	0.55KW
Cooling Motor	0.045KW	0.12KW
Maximum Grinding Diameter	160mm	200mm
Maximum Grinding Stroke	200mm	250mm
The Diameter of Grinding Wheel	135mm	150mm
Minimum step	0.01mm	0.01mm
Measurement (L*W*H)	820*1020*1850mm	820*820*1810mm
Weight	650KG	600KG

Detailed Photos
FAQ
1. Who are we?
A:We are based in Jiangsu, China, start from 2011,sell to Southeast Asia(20.00%),Eastern Europe(20.00%), WesternEurope(10.00%), North America(10.00%), Northern Europe(5.00%), Central America(5.00%),SouthAmerica(5.00%),Eastern Asia(5.00%),South Asia(5.00%),Oceania(5.00%),Southern Europe(5.00%),Africa(3.00%),MidEast(2.00%). There are total about 11-50 people in our office.
2.Which payment terms you can accept?
A: We can accept flexible payment include Bank Transfer, LC, DP, West Union, Paypal, or Combination terms as negotiation.
3.Which shipping way can you provide?
A: We can provide shipping by sea, by air, by express and etc according to customer requirements.
4.How to place order?
A: When you are ready to order, please contact us for confirm the suitable solution & plan & model. What cannot be ignored is you should provide a copy purchase order to ensure that your order is processed properly.
5.Do you have an inspection procedure for the product?
A: Yes, We have a strict inspection of product quality and packing.

---
